Weidmuller 7760054115
Estimated Delivery between and with free shipping.
Overnight shipping is also available.





Description
Weidmuller 7760054115 is now available new, surplus, and used from Williams Automation.
If you need a specific firmware or series relating to this item, please call or email us with your request.
We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you require one.
Please note we offer UPS Next Day Air shipping for all orders. Please be sure to select next day shipping at checkout, and we will provide same-day shipment.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Approvals
- Approvals
- CE, CULUS, EAC
- ROHS
- Conform
- UL File Number Search
- E366074
Classifications
- eClass 10.0
- 27-21-01-20
- eClass 9.0
- 27-21-01-20
- eClass 9.1
- 27-21-01-20
- ETIM 6.0
- EC002653
- ETIM 7.0
- EC002653
Connection Data
- Clamping range, max.
- 2.5 mm²
- Clamping range, min.
- 0.5 mm²
- Clamping range, rated connection
- 2.5 mm²
- Tightening torque, max.
- 0.6 Nm
- Tightening torque, min.
- 0.4 Nm
- Type of connection
- Screw connection
- Wire connection cross section AWG, max.
- AWG 12
- Wire connection cross section AWG, min.
- AWG 26
Dimensions And Weights
- Depth
- 113.7 mm
- Depth (inches)
- 4.476 inch
- Height
- 117.2 mm
- Height (inches)
- 4.614 inch
- Net weight
- 157 g
- Weight
- 157 g
- Width
- 12.5 mm
- Width (inches)
- 0.492 inch
Environmental Product Compliance
- REACH SVHC
- Lead 7439-92-1
General Data
- Accuracy
- < 0.1 % of end value
- Configuration
- none
- Current consumption
- ≤60 mA (24V power supply, 20mA output)
- Galvanic isolation
- 3-way isolator, between input ⁄ output ⁄ supply
- Rail
- TS 35
- Step response time
- ≤ 0,5 ms
- Temperature coefficient
- 80 ppm/K
- Voltage supply
- 20…30 V DC
Input
- Input current
- 0...20 mA, 4…20mA
- Input signal
- 2-/3-wire transmitter, HART signal® bidirectional
- Number of inputs
- 1
- Sensor supply
- > 17 V DC at 20 mA, max 30 V @ open circuit, max 50 mA @ short-circuit
- Voltage drop
- ca. 3.8 V @ RLoad = 0 Ω; ca. 15 V @ RLoad = 600 Ω; (Iinput = 20 mA)
Insulation Coordination
- EMC standards
- EN 61010-1:2011, UL 61010-1, EN 61326-1
- Galvanic isolation
- 3-way isolator, between input ⁄ output ⁄ supply
- Impulse withstand voltage
- 4 kV (1.2/50 µs)
- Insulation voltage
- 2 kV inputs / outputs / power supply
- Insulation voltage input or output/supply
- 2 kV inputs / outputs / power supply
- Pollution severity
- 2
- Surge voltage category
- III
Output
- load impedance current
- < 300 Ω
- Number of outputs
- 2
- Output current
- 0...20 mA, 4...20 mA, HART® digital signal
Product Information
- Product information
- The non-adjustable DC isolating amplifier ACT20P-CI-2CO isolates analogue standard current signals from a power source or from a 2- or 3-wire sensor. An analogue input current signal is converted linearly and doubled to provide two galvanically isolated output current signals. The power supply is galvanically isolated from the input and output (4-way isolation). Properties HART-compatible for 0.5 - 2.5 kHz The active or passive mA signal inputs are fully galvanically isolated. Operating status display on a front panel LED Galvanic 4-way isolation between input, output and supply.
Ratings Iecex/Atex/Cul
- Certificate no. (cULus)
- E366074
Temperatures
- Humidity
- 5...95 %, no condensation
- Operating temperature
- -20 °C...60 °C
- Operating temperature, max.
- 60 °C
- Operating temperature, min.
- -20 °C
- Storage temperature
- -40 °C...85 °C
- Storage temperature, max.
- 85 °C
- Storage temperature, min.
- -40 °C
Williams Automation sells Weidmuller parts at huge savings. Search to find the part you need today. If you can't find what you are looking for please Request A Quote from us and we will provide a timely response. You can also call us at 803-761-7027. We look forward to working with you to assist in the best way we can for your industrial needs.
