Weidmuller 2661710000
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
PCB plug-in connector, RJ45 jacks transformer, 100 MBit/s, POE , THT/THR solder connection, 90°, Latch option: bottom, Number of poles: 10, TapeRJ45MP R1D 3.3E4N RL
Weidmuller 2661710000 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Approvals
- ROHS
- Conform
Classifications
- eClass 10.0
- 27-44-04-02
- eClass 9.0
- 27-44-04-02
- eClass 9.1
- 27-44-04-02
- ETIM 6.0
- EC002637
- ETIM 7.0
- EC002637
Dimensions And Weights
- Net weight
- 10.61 g
Electrical Properties
- Dielectric strength, contact / contact
- 1000 V DC
- Dielectric strength, contact / shield
- 1500 V DC
- Insulation strength
- > 500 MΩ
Environmental Product Compliance
- REACH SVHC
- Lead 7439-92-1
Material Data
- Insulation strength
- > 500 MΩ
Packing
- Packaging
- Tape
- VPE height
- 345 mm
- VPE length
- 345 mm
- VPE width
- 125 mm
System Specifications
- Latch option
- bottom
- Mounting onto the PCB
- THT/THR solder connection
- Number of poles
- 10
- Outgoing elbow
- 90°
- Pitch in inches (P)
- 0.05 inch
- Pitch in mm (P)
- 1.27 mm
- Plugging cycles
- 750
- Product family
- OMNIMATE Data - RJ45 jacks transformer
- Protection degree
- IP20
- Transmission rate
- 100 MBit/s, POE
