Weidmuller 2476340000
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
D-SERIES DRI, Relay module, Number of contacts: 1 CO contact AgNi, Rated control voltage: 12 V DC, Continuous current: 10 A, Screw connectionDRIKIT 12VDC 1CO LD
Weidmuller 2476340000 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Approvals
- Approvals
- CE, EAC
Classifications
- eClass 10.0
- 27-37-16-01
- eClass 9.0
- 27-37-16-01
- eClass 9.1
- 27-37-16-01
- ETIM 6.0
- EC001437
- ETIM 7.0
- EC001437
Connection Data
- Blade size
- size PH1
- Clamping range, max.
- 4 mm²
- Clamping range, min.
- 0.25 mm²
- Clamping range, rated connection
- 1.5 mm²
- Conductor cross-section, flexible, AEH (DIN 46228-1), max.
- 4 mm²
- Conductor cross-section, flexible, AEH (DIN 46228-1), min.
- 0.25 mm²
- Gauge to IEC 60947-1
- A3
- Stripping length, rated connection
- 8 mm
- Tightening torque, max.
- 0.8 Nm
- Tightening torque, min.
- 0.5 Nm
- Wire connection cross section, finely stranded, max.
- 4 mm²
- Wire connection cross-section, finely stranded, min.
- 0.25 mm²
- Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, max.
- 4 mm²
- Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, min.
- 0.25 mm²
- Wire connection method
- Screw connection
- Wire cross-section, solid, max.
- 4 mm²
- Wire cross-section, solid, min.
- 0.25 mm²
Contact Data
- Contact type
- 1 CO contact (AgNi)
- Mechanical service life
- 10 x 106 switching cycles
Dimensions And Weights
- Depth
- 67.7 mm
- Depth (inches)
- 2.665 inch
- Height
- 80.2 mm
- Height (inches)
- 3.157 inch
- Net weight
- 58.5 g
- Width
- 15.8 mm
- Width (inches)
- 0.622 inch
Environmental Product Compliance
- REACH SVHC
- Lead 7439-92-1
Further Details Of Approvals / Standards
- Certificate no. (cURus) base
- E355547
- Certificate no. (cURus) relay
- E312083
- Standards
- IEC 61810-1, EN 60664-1:2007, EN 61000-6-2:2005, EN 61000-6-4:2007 + A1:2011
General Data
- Colour
- black
- Mechanical switch position indicator
- No
- Rail
- TS 35
- Test button
- No
Input
- Coil resistance
- 270 Ω ± 10 %
- Power rating
- 530 mW
- Protective circuit
- Free-wheeling diode
- Pull-in/drop-out voltage, typ.
- 9 V / 1.8 V DC
- Rated control voltage
- 12 V DC
- Rated current DC
- 44,4 mA
- Status indicator
- Green LED
Insulation Coordination
- Creepage and clearance distance input – output
- ≥ 3 mm
- Dielectric strength, Input/Output
- 4 kVeff / 1 Min.
- Dielectric strength of open contact
- 1 kVeff / 1 min
- Impulse withstand voltage
- 4.8 kV (1.2/50 µs)
- Insulating material group
- IIIb
- Pollution severity
- 2
- Protection degree
- IP20
- Rated voltage
- 250 V
- Surge voltage category
- III
Output
- AC switching capacity (resistive), max.
- 2500 VA
- Continuous current
- 10 A
- DC switching capacity (resistive), max.
- 240 W @ 24 V
- Max. switching frequency at rated load
- 0.1 Hz
- Max. switching voltage, AC
- 250 V
- Max. switching voltage, DC
- 250 V
- Min. switching power
- 10 mA @ 12 V, 100 mA @ 5 V
- Rated switching voltage
- 250 V AC
- Switch-off delay
- ≤ 10 ms
- Switch-on delay
- ≤ 15 ms
Temperatures
- Humidity
- 35...85 % rel. humidity, no condensation
- Operating temperature
- -40 °C...55 °C
- Operating temperature, max.
- 55 °C
- Operating temperature, min.
- -40 °C
- Storage temperature
- -40 °C...85 °C
- Storage temperature, max.
- 85 °C
- Storage temperature, min.
- -40 °C
