Weidmuller 2456870000
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
ACT20-FEED-IN-PRO-P
Weidmuller 2456870000 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Approvals
- Approvals
- EAC
- ROHS
- Conform
Classifications
- eClass 10.0
- 27-24-26-10
- eClass 9.0
- 27-24-26-10
- eClass 9.1
- 27-24-26-10
- ETIM 6.0
- EC001600
- ETIM 7.0
- EC001600
Connection Data
- Type of connection
- PUSH IN
- Wire connection cross section AWG, max.
- AWG 14
- Wire connection cross section AWG, min.
- AWG 26
- Wire connection cross section, finely stranded, max.
- 2.5 mm²
- Wire connection cross-section, finely stranded, min.
- 0.2 mm²
- Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, max.
- 2.5 mm²
- Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, min.
- 0.2 mm²
- Wire cross-section, solid, max.
- 2.5 mm²
- Wire cross-section, solid, min.
- 0.2 mm²
Dimensions And Weights
- Depth
- 113.6 mm
- Depth (inches)
- 4.472 inch
- Height
- 117.2 mm
- Height (inches)
- 4.614 inch
- Net weight
- 173 g
- Weight
- 140 g
- Width
- 22.5 mm
- Width (inches)
- 0.886 inch
Environmental Product Compliance
- REACH SVHC
- Lead 7439-92-1
General Data
- Degree of efficiency
- 0,976
- Power consumption
- < 2 W
- Rail
- TS 35, CH20M Bus
- Voltage supply
- 21.6...26.4 V DC
Input
- Backup power supply
- 21.6...26.4 V DC
- Input current
- max. 4 A
- Input voltage
- 21.6…26.4 V DC
- Number of inputs
- 2
- Supply voltage (input)
- 21.6...26.4 V DC
- Trigger level for the power supply
- Fault < 21 V DC
Insulation Coordination
- EMC standards
- IEC 61326-1, NE 21
Output
- Number of outputs
- 1
- Output current
- max. 4 A, (Supply of e.g. 110 devices of ACT20M-CI-2CO-S on one CH20M BUS)
- Output power
- 96 W
- Output voltage, note
- Input voltage -0.5 V DC / 4 A
- Supply voltage (output)
- 24 V DC
Output (Digital)
- AC power, max.
- 500 VA / 60 W
- Alarm function
- Device error
- Continuous current
- 2 A
- Max. switching voltage, AC
- 250 V
- Type
- Relay, 1 CO contact
Rated Data Ul
- UL certificate
- E337701.pdf
Temperatures
- Ambient temperature
- -20...+60 °C
- Humidity
- 95 %, no condensation
- Storage temperature
- -20 °C...85 °C
- Storage temperature, max.
- 85 °C
- Storage temperature, min.
- -20 °C
