Weidmuller 1444240000

Additional Technical Data

• Type of mounting
  • Snap-on

Approvals

• ROHS
  • Conform

Classifications

• eClass 10.0
  • 27-14-11-16
• eClass 9.0
  • 27-14-11-16
• eClass 9.1
  • 27-14-11-16
• ETIM 6.0
  • EC000899
• ETIM 7.0
  • EC000899

Conductors For Clamping (Rated Connection)

• Number of connections
  • 2
• Stripping length
  • 11 mm
• Type of connection
  • Screw connection

Dimensions And Weights

• Depth
  • 58 mm
• Depth (inches)
  • 2.283 inch
• Height
  • 81 mm
• Height (inches)
  • 3.189 inch
• Net weight
  • 104 g
• Width
  • 54 mm
• Width (inches)
  • 2.126 inch

Fuse Terminals

• Cartridge fuse
  • max. 3W for gG/gL max. 1.2W for aM

Material Data

• Colour
  • dark beige
• Material
  • PA 66/6
• UL 94 flammability rating
  • V-0

Rating Data

• Current at maximum wires
  • 32 A
• Pollution severity
  • 3
• Power loss in accordance with IEC 60947-7-x
  • 3.23 W
• Rated cross-section
  • 25 mm²
• Rated current
  • 32 A
• Rated impulse withstand voltage
  • 6 kV
• Rated voltage
  • 690 V
• Rated voltage to adjoining terminal
  • 690 V
• Volume resistance according to IEC 60947-7-x
  • 0.32 mΩ

System Specifications

• Levels cross-connected internally
  • No
• N-function
  • No
• Number of clamping points per level
  • 2
• Number of levels
  • 1
• Number of potentials
  • 1
• Number of potentials per tier
  • 1
• PE connection
  • No
• PE function
  • No
• PEN function
  • No
• Rail
  • TS 35

Temperatures

• Continuous operating temp., max.
  • 120 °C
• Continuous operating temp., min.
  • -50 °C
• Storage temperature
  • 10 °C...40 °C
• Storage temperature, max.
  • 40 °C
• Storage temperature, min.
  • 10 °C
