Weidmuller 1427960000
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Weidmuller 1427960000 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Approvals
- Approvals
- CULUS
- ROHS
- Conform
- UL File Number Search
- E316369
Classifications
- eClass 10.0
- 27-44-03-90
- eClass 9.0
- 27-44-03-90
- eClass 9.1
- 27-18-90-90
- ETIM 6.0
- EC001121
- ETIM 7.0
- EC001121
Dimensions And Weights
- Net weight
- 28.1 g
- Wall thickness, max.
- 3 mm
- Wall thickness, min.
- 1 mm
Electrical Properties
- Contact resistance
- ≤ 30 mΩ
- Insulation strength
- ≥ 1000 MΩ
Environmental Product Compliance
- REACH SVHC
- Lead 7439-92-1
General Info
- Colour
- black
- Connection 1
- USB A
- Connection 2
- USB A
- Contact surface
- Gold over nickel
- Description of article
- FrontCom Micro USB coupling, USB 3.0
- Housing main material
- PA UL 94 V0
- Plugging cycles
- ≥ 1500
- Protection degree
- IP65, in closed state
- Shielding
- 360° shield contact
- Shielding material
- Stainless steel, rust-proof, nickel-plated
- Tightening torque fixing nut
- 2 Nm
- Type of mounting
- Cabinet, Distribution box
- Wiring
- Type A
Standards
- Certificate no. (cULus)
- E316369
- Connector standard
- IEC 61076-3-107
- UL standard for communication accessories
- UL 1863
Temperatures
- Operating temperature
- -40 °C...70 °C
- Operating temperature, max.
- 70 °C
- Operating temperature, min.
- -40 °C
