Weidmuller 1375510000

Approvals

• Approvals
  • CULUS, DETNORVER, DNV GL, EAC, FMEX, IECEXKEM, KEMAATEX
• ROHS
  • Conform
• UL File Number Search
  • E337701

Classifications

• eClass 10.0
  • 27-21-01-29
• eClass 9.0
  • 27-21-01-29
• eClass 9.1
  • 27-21-01-29
• ETIM 6.0
  • EC002919
• ETIM 7.0
  • EC002919

Connection Data

• Clamping range, max.
  • 2.5 mm²
• Clamping range, min.
  • 0.5 mm²
• Clamping range, rated connection
  • 2.5 mm²
• Tightening torque, max.
  • 0.6 Nm
• Tightening torque, min.
  • 0.4 Nm
• Type of connection
  • Screw connection
• Wire connection cross section AWG, max.
  • AWG 14
• Wire connection cross section AWG, min.
  • AWG 30

Data For Ex Applications (Atex)

• Marking
  • II 3 G Ex nA IIC T4 Gc

Dimensions And Weights

• Depth
  • 114.3 mm
• Depth (inches)
  • 4.5 inch
• Height
  • 112.5 mm
• Height (inches)
  • 4.429 inch
• Net weight
  • 89 g
• Width
  • 6.1 mm
• Width (inches)
  • 0.24 inch

Environmental Product Compliance

• REACH SVHC
  • Lead 7439-92-1

General Data

• Accuracy
  • absolute accuracy: < ±0.05 % of the measurement range, Basic accuracy: < ±0.1°C
• Configuration
  • DIP switch
• Galvanic isolation
  • 3-way isolator
• Power consumption, max.
  • 0.7 W
• Power consumption, typ.
  • 0.49 W
• Rail
  • TS 35
• Step response time
  • ≤ 30 ms
• Temperature coefficient
  • ≤0.01 % of the measurement range⁄°C or 0.02 °C ⁄ °C
• Voltage supply
  • 24 V DC ± 30 %

Input

• Influence of the sensor cable resistance
  • < 0.002 Ω⁄Ω (@ 3⁄4-wire)
• Input measurement range
  • PT100 -200…+850 °C
• Line resistance in measuring circuit
  • ≤ 50 Ω
• Number of inputs
  • 1
• Sensor
  • PT100 / 2-/3-/4-wire
• Temperature input range
  • Configurable, min. measurement range 10°C (RTD)

Insulation Coordination

• EMC standards
  • IEC 61326-1, NE 21
• Galvanic isolation
  • 3-way isolator
• Insulation voltage
  • 2.5 kVeff /1 min.
• Pollution severity
  • 2
• Rated voltage
  • 300 Veff
• Surge voltage category
  • II

Output

• load impedance current
  • ≤ 600 Ω
• load impedance voltage
  • ≥ 10 kΩ
• Number of outputs
  • 1
• Output current
  • configurable, 0...20 mA, 4...20 mA
• Output signal limit
  • < 4 mA (average), < 60 mA (pulse current), low duty cycle
• Output voltage, note
  • configurable, 0(2)...10 V, 0(1)...5 V
• Wire break detection
  • 3.5 mA ⁄ 23 mA ⁄ none

Probability Of Failure

• MTBF
  • 152 Years

Product Information

• Product information
  • The ACT20M-RTI-AO-S configurable temperature transducer isolates and converts analogue signals. An analogue RTD input signal (Type Pt100) is linearly converted into an analogue output signal and galvanically isolated. The power supply is galvanically isolated from the input and output (3-way isolation) and this is done with direct wiring or over the Weidmüller rail bus.

Rated Data Ul

• UL certificate
  • E337701.pdf

Ratings Iecex/Atex/Cul

• Certificate No. (ATEX)
  • KEMA10ATEX0183X
• Certificate no. (cULus)
  • E337701
• Certificate No. (IECEX)
  • IECEXKEM10.0090X

Temperatures

• Ambient temperature
  • -25 °C...+70 °C
• Humidity
  • 95 %, no condensation
• Storage temperature
  • -40 °C...85 °C
• Storage temperature, max.
  • 85 °C
• Storage temperature, min.
  • -40 °C
