Weidmuller 1286880000

Approvals

• Approvals
  • CULUS, CULUSEX, DEMKOATEX, DNV GL, EAC, KOREANCERT
• ROHS
  • Conform
• UL File Number Search
  • E141197

Classifications

• eClass 10.0
  • 19-17-01-32
• eClass 9.0
  • 19-17-01-14
• eClass 9.1
  • 19-17-01-14
• ETIM 6.0
  • EC001467
• ETIM 7.0
  • EC001467

Dimensions And Weights

• Depth
  • 105 mm
• Depth (inches)
  • 4.134 inch
• Height
  • 135 mm
• Height (inches)
  • 5.315 inch
• Length
  • 105 mm
• Length (inches)
  • 4.134 inch
• Net weight
  • 765 g
• Width
  • 53.6 mm
• Width (inches)
  • 2.11 inch

Emc Conformity And Approvals

• EMC standards
  • EN 55032, EN 55024, CISPR 32, FCC Part 15 Subpart B Class A, IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV, IEC 61000-4-3 RS: 80 MHz bis 1 Ghz: 3 V/m, IEC 61000-4-4 EFT: Power: 2 kV; Signal: 2 kV, IEC 61000-4-5 Surge: Power: 1 kV; Signal: 1 kV, IEC 61000-4-6 CS: 3 V/m, IEC 61000-4-8, IEC 61000-4-11
• Explosive risk zone
  • UL/cUL, Class I, Division 2, Groups A, B, C and D, ATEX Zone 2 Ex nA nC IIC T4 Gc
• Free fall
  • According to IEC 60068-2-32
• Security
  • UL508, UL60950-1, CSA C22.2 No. 60950-1, EN60950-1
• Ship use
  • DNV-GL
• Shock
  • according to IEC 60068-2-27
• Vibration
  • according to IEC 60068-2-6

Environmental Conditions

• Humidity
  • 5 to 95 % (non-condensing)
• Operating temperature, max.
  • 75 °C
• Operating temperature, min.
  • -40 °C
• Storage temperature, max.
  • 85 °C
• Storage temperature, min.
  • -40 °C

Environmental Product Compliance

• REACH SVHC
  • Lead 7439-92-1

Fibre Optic 100Basefx

• Link budget multimode
  • 12 dB
• Max. TX multi-mode
  • -10 dBm
• Min. TX multi-mode
  • -20 dBm
• Receive sensitivity multi-mode
  • -32 dBm
• System reserve multi-mode
  • -6 dBm
• Typical distances multi-mode
  • 5 km (50/125 μm, 800 MHz*km fibre optic cable), 4 km (62.5/125 μm, 500 MHz*km fibre optic cable)
• Wavelength multi-mode
  • 1,300 nm

Guarantee

• Time interval
  • 5 years

Interfaces

• Alarm contact
  • 1 relay output with a current capacity of 1 A at 24 V DC
• DIP switch
  • 100BaseFX full-/half-duplex mode, Port surveillance
• Fibre-optic ports
  • 100BaseFX ports (SC connector), Multimode
• LED indicator
  • PWR1, PWR2, FAULT, 10/100M (TP-Port), 100M (fibre-optic port)., FDX/COL (Fibre port)
• Number of ports
  • 1x RJ45, 1 * SC Multi-mode
• RJ45 ports
  • 10/100BaseT(X)

Mtbf

• Database
  • MIL-HDBK-217F, GB 25°C
• MTBF
  • 401,000 hrs

Power Supply

• Connection type
  • 1 removable 6-pin terminal block
• Current consumption
  • 0.16 A at 24 V
• Overload current protection
  • 1.1 A
• Reverse polarity protection
  • Available
• Supply voltage, max.
  • 45 V DC
• Supply voltage, min.
  • 12 V DC
• Voltage supply
  • 24 V DC, 2 redundant inputs

Technical Data

• Housing main material
  • metal
• Protection degree
  • IP30
• Type of mounting
  • DIN rail, Panel (with optional mounting kit)

Technology

• Standard
  • IEEE 802.3 for 10BaseT, IEEE 802.3u for 100BaseT(X) and 100BaseFX
