Weidmuller 1283230000
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
MICROOPTO, solid-state relais, 1 NO contact (Intelligent POWER MOS-FET), Rated control voltage: 24 V DC ±20 % , Rated switching voltage: 8...30 V DC, Continuous current: 2 A, Screw connectionMOS 24VDC/8-30VDC 2A E
Weidmuller 1283230000 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Approvals
- Approvals
- CE, DNV GL, EAC
- ROHS
- Conform
Classifications
- eClass 10.0
- 27-37-16-04
- eClass 9.0
- 27-37-16-04
- eClass 9.1
- 27-37-16-04
- ETIM 6.0
- EC001504
- ETIM 7.0
- EC001504
Connection Data
- Blade size
- 0.6 x 3.5 mm
- Clamping range, max.
- 4 mm²
- Clamping range, min.
- 0.5 mm²
- Clamping range, rated connection
- 2.5 mm²
- Conductor cross-section, flexible, AEH (DIN 46228-1), max.
- 1.5 mm²
- Conductor cross-section, flexible, AEH (DIN 46228-1), min.
- 0.5 mm²
- Stripping length, rated connection
- 7 mm
- Tightening torque, max.
- 0.6 Nm
- Tightening torque, min.
- 0.4 Nm
- Wire connection cross section, finely stranded, max.
- 2.5 mm²
- Wire connection cross-section, finely stranded, min.
- 0.5 mm²
- Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, max.
- 1.5 mm²
- Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, min.
- 0.5 mm²
- Wire connection method
- Screw connection
- Wire cross-section, solid, max.
- 4 mm²
- Wire cross-section, solid, min.
- 0.5 mm²
Contact Data
- Contact type
- 1 NO contact (Intelligent POWER MOS-FET)
Control Side
- Cut-in / dropout voltage
- 13.8 V / 13.6 V DC
- Power rating
- ≤ 170 mW
- Protective circuit
- Varistor, Reverse polarity protection
- Rated control voltage
- 24 V DC ±20 %
Dimensions And Weights
- Depth
- 97.8 mm
- Depth (inches)
- 3.85 inch
- Height
- 88.1 mm
- Height (inches)
- 3.468 inch
- Net weight
- 35.81 g
- Width
- 6.1 mm
- Width (inches)
- 0.24 inch
Environmental Product Compliance
- REACH SVHC
- Lead 7439-92-1
Further Details Of Approvals / Standards
- Certificate No. (GERMLLOYD)
- 54853-08
- Standards
- DIN EN 50178
General Data
- Colour
- black
- Rail
- TS 35
- UL 94 flammability rating
- V-0
Insulation Coordination
- Dielectric strength for control side - load side
- 350 Veff / 1 min.
- Dielectric strength to mounting rail
- 350 Veff / 1 min.
- Impulse withstand voltage
- 500 V (1,2/50 μ)
- Pollution severity
- 2
- Protection degree
- IP20
- Rated voltage
- 30 V
- Surge voltage category
- III
Load Side
- Continuous current
- 2 A
- Leakage current
- < 10 µA
- Load category
- LC A
- Load side status indicator
- LED green, output switched, LED red, short-circuit /overload at the output
- Max. switching current
- 2 A
- max. switching frequency (DC control voltage)
- 10 Hz
- Min. switching current
- 100 µA
- Nominal auxiliary voltage
- 8…30 V DC / max. 6 mA
- Protective circuit, load side
- Varistor, Free-wheeling diode
- Rated switching voltage
- 8...30 V DC
- Short-circuit-proof
- Yes (thermal cut-out)
- Switch-off delay
- < 0.5 ms
- Switch-on delay
- 0.1 ms
- Voltage drop at max. load
- ≤ 50 mV
Probability Of Failure
- MTTF
- 847 Years
Product Information
- Product information
- The cable lengths must not exceed 30 m.
Temperatures
- Humidity
- 5-95% relative humidity, Tu = 55°C, without condensation
- Operating temperature
- -25 °C...60 °C
- Operating temperature, max.
- 60 °C
- Operating temperature, min.
- -25 °C
- Storage temperature
- -40 °C...80 °C
- Storage temperature, max.
- 80 °C
- Storage temperature, min.
- -40 °C
