Weidmuller 1165790000
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Weidmuller 1165790000 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Approvals
- Approvals
- EAC
- ROHS
- Conform
Classifications
- eClass 10.0
- 27-44-02-02
- eClass 9.0
- 27-44-02-02
- eClass 9.1
- 27-44-02-02
- ETIM 6.0
- EC000437
- ETIM 7.0
- EC000437
- UNSPSC
- 30-21-18-01
Design
- Cable entry
- For bases
- Product family
- HDC enclosures
- Product type
- Enclosures
- Type
- Cover
Dimensions
- Cable entry
- For bases
- Height of housing B
- 17 mm
- Total length housing
- 94 mm
- Width housing C
- 82.5 mm
Dimensions And Weights
- Depth
- 94 mm
- Depth (inches)
- 3.701 inch
- Height
- 17 mm
- Height (inches)
- 0.669 inch
- Net weight
- 117 g
- Width
- 98.3 mm
- Width (inches)
- 3.87 inch
Environmental Product Compliance
- REACH SVHC
- Lead 7439-92-1
General Data
- EMC housings
- No
- Housing main material
- diecast aluminium
- Material of locking element
- Stainless steel, rust-proof
- Protection degree
- IP65
- Surface finish
- Powder coating
- Tightening torque
- 2 Nm
General Descriptions
- Protection degree
- IP65
- Size
- 10
Material
- Colour
- grey
Temperatures
- Limit temperature
- -40 °C ... 125 °C
Version
- Cable entry
- For bases
- Clamp version
- Side-locking clamp
- Design
- Standard
- Design of housing
- Cover for lower part of housing
- Design of locking system
- Side-locking clamp on lower side
- Size
- 10
- Suitable for ModuPlug
- Yes
- Tightening torque
- 2 Nm
- Top part/bottom part/lid
- Cover
- Type
- Cover
