Weidmuller 1133950000
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
D-SERIES DRL, Relay, Number of contacts: 4 CO contact AgCdO, Rated control voltage: 115 V AC, Continuous current: 10 A, Flat blade connections (4.8 mm x 0.5 mm)DRL570615L
Weidmuller 1133950000 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Approvals
- Approvals
- CE, cURus, EAC
- ROHS
- Conform
- UL File Number Search
- E312083
Classifications
- eClass 10.0
- 27-37-16-01
- eClass 9.0
- 27-37-16-01
- eClass 9.1
- 27-37-16-01
- ETIM 6.0
- EC001437
- ETIM 7.0
- EC001437
Connection Data
- Wire connection method
- Flat blade connections (4.8 mm x 0.5 mm)
Contact Data
- Contact resistance
- ≤ 50 mΩ
- Contact type
- 4 CO contact (AgCdO)
- Mechanical service life
- 10 x 106 switching cycles
Dimensions And Weights
- Depth
- 36 mm
- Depth (inches)
- 1.417 inch
- Height
- 28 mm
- Height (inches)
- 1.102 inch
- Net weight
- 74.2 g
- Width
- 41.5 mm
- Width (inches)
- 1.634 inch
Environmental Product Compliance
- REACH SVHC
- Lead 7439-92-1
Further Details Of Approvals / Standards
- Certificate No. (cURus)
- E312083
- Standards
- IEC 61810-1, EN 60664-1:2007, EN 61000-6-2:2005, EN 61000-6-4:2007 + A1:2011, UL 508
General Data
- Colour
- Transparent
- Mechanical switch position indicator
- Yes
- Test button
- No
- UL 94 flammability rating
- V-2
Input
- Coil resistance
- 1680 Ω ± 10 %
- Power rating
- 2.5 VA
- Pull-in/drop-out voltage, typ.
- 92 V / 34.5 V AC
- Rated control voltage
- 115 V AC
- Rated current DC
- 25.5 mA
- Status indicator
- red LED
Insulation Coordination
- Creepage and clearance distance input – output
- ≥ 4 mm
- Dielectric strength, Input/Output
- 2 kVeff / 1 min
- Dielectric strength of neighbouring contacts
- 1.2 kVeff /1 min.
- Dielectric strength of open contact
- 1.2 kVeff /1 min.
- Impulse withstand voltage
- 5 kV (1.2/50 µs)
- Insulating material group
- IIIa
- Pollution severity
- 3
- Protection degree
- IP20
- Rated voltage
- 250 V
- Surge voltage category
- III
Output
- AC switching capacity (resistive), max.
- 2500 VA
- Continuous current
- 10 A
- DC switching capacity (resistive), max.
- 240 W @ 24 V
- Inrush current
- 50 A / 50 ms
- Max. switching frequency at rated load
- 0.1 Hz
- Max. switching voltage, AC
- 250 V
- Min. switching power
- 100 mA @ 12 V
- Rated switching voltage
- 250 V AC
- Switch-off delay
- < 20 ms
- Switch-on delay
- < 20 ms
Rated Data Ul
- Certificate No. (cURus)
- E312083
Temperatures
- Humidity
- 35 % to 85 % relative humidity level
- Operating temperature
- -25 °C...55 °C
- Operating temperature, max.
- 55 °C
- Operating temperature, min.
- -25 °C
- Storage temperature
- -25 °C...55 °C
- Storage temperature, max.
- 55 °C
- Storage temperature, min.
- -25 °C
