Weidmuller 1132290000
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
TERMSERIES, solid-state relais, 1 NO contact (Triac (zero-cross switch)), Rated control voltage: 10…32 V DC , Rated switching voltage: 12...275 V AC, Continuous current: 1 A, Plug-in connectionSSR 24VDC/max.240VAC 1A
Weidmuller 1132290000 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Approvals
- Approvals
- EAC
- ROHS
- Conform
Classifications
- eClass 10.0
- 27-37-16-04
- eClass 9.0
- 27-37-16-04
- eClass 9.1
- 27-37-16-04
- ETIM 6.0
- EC001504
- ETIM 7.0
- EC001504
Connection Data
- Pitch in mm (P)
- 5 mm
- Wire connection method
- Plug-in connection
Contact Data
- Contact type
- 1 NO contact (Triac (zero-cross switch))
Control Side
- Cut-in / dropout voltage
- 10 V / 8 V DC
- Nominal control current
- 3…13 mA
- Rated control voltage
- 10…32 V DC
- Status indicator
- No
Dimensions And Weights
- Depth
- 15 mm
- Depth (inches)
- 0.591 inch
- Height
- 29 mm
- Height (inches)
- 1.142 inch
- Net weight
- 5.2 g
- Width
- 12.7 mm
- Width (inches)
- 0.5 inch
General Data
- Colour
- black
Insulation Coordination
- Dielectric strength for control side - load side
- 2.5 kVeff
Load Side
- Continuous current
- 1 A
- Inrush current
- 15 A / 10 ms
- Leakage current
- < 1.5 mA
- Min. switching current
- 50 mA
- Output voltage frequency range
- 50 / 60 Hz
- Protective circuit, load side
- RC element
- Rated switching current
- 1 A
- Rated switching voltage
- 12...275 V AC
- Switch-off delay
- ≤ 10 ms
- Switch-on delay
- ≤ 10 ms
- Voltage drop at max. load
- ≤ 1 V
Probability Of Failure
- MTTF
- 1,150 Years
Temperatures
- Operating temperature
- -20 °C...60 °C
- Operating temperature, max.
- 60 °C
- Operating temperature, min.
- -20 °C
- Storage temperature
- -40 °C...70 °C
- Storage temperature, max.
- 70 °C
- Storage temperature, min.
- -40 °C
