Weidmuller 1123350000
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
TERMSERIES, Relay bases, Number of contacts: 1 CO contact, Rated control voltage: 12 V DC ±20 %, Continuous current: 10 A, Tension-clamp connectionTRZ 12VDC 1CO EMPTY
Weidmuller 1123350000 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Approvals
- Approvals
- CE, cURus, EAC
- ROHS
- Conform
- UL File Number Search
- E223759
Classifications
- eClass 10.0
- 27-37-16-03
- eClass 9.0
- 27-37-16-03
- eClass 9.1
- 27-37-16-03
- ETIM 6.0
- EC001456
- ETIM 7.0
- EC001456
Connection Data
- Blade size
- 0.6 x 3.5 mm
- Clamping range, max.
- 2.5 mm²
- Clamping range, min.
- 0.14 mm²
- Clamping range, rated connection
- 1.5 mm²
- Conductor cross-section, flexible, AEH (DIN 46228-1), max.
- 1.5 mm²
- Conductor cross-section, flexible, AEH (DIN 46228-1), min.
- 0.14 mm²
- Gauge to IEC 60947-1
- A1, B1
- Stripping length, rated connection
- 8 mm
- Twin wire-end ferrules, max.
- 1 mm²
- Twin wire-end ferrules, min.
- 0.5 mm²
- Wire connection cross section AWG, max.
- AWG 14
- Wire connection cross section AWG, min.
- AWG 26
- Wire connection cross section, finely stranded, max.
- 2.5 mm²
- Wire connection cross-section, finely stranded, min.
- 0.14 mm²
- Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, max.
- 1.5 mm²
- Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, min.
- 0.14 mm²
- Wire connection method
- Tension-clamp connection
- Wire cross-section, finely stranded, max. (AWG)
- AWG 14
- Wire cross-section, finely stranded, min. (AWG)
- AWG 26
- Wire cross-section, solid, max.
- 2.5 mm²
- Wire cross-section, solid, min.
- 0.14 mm²
Contact Data
- Contact type
- 1 CO contact
Control Side
- Coil voltage of the replacement relay
- 12 V DC
- Coil voltage of the replacement relay deviating from the rated control voltage
- No
- Protective circuit
- Free-wheeling diode, Reverse polarity protection
- Rated control voltage
- 12 V DC ±20 %
- Status indicator
- Green LED
Dimensions And Weights
- Depth
- 87.8 mm
- Depth (inches)
- 3.457 inch
- Height
- 90.5 mm
- Height (inches)
- 3.563 inch
- Net weight
- 22.8 g
- Width
- 6.4 mm
- Width (inches)
- 0.252 inch
Environmental Product Compliance
- REACH SVHC
- Lead 7439-92-1
Further Details Of Approvals / Standards
- Certificate No. (cURus)
- E223759
- Standards
- DIN EN 50178
General Data
- Colour
- black
- Rail
- TS 35
- UL 94 flammability rating
- V-0
Insulation Coordination
- Dielectric strength to mounting rail
- 4 kVeff / 1 Min.
- Impulse withstand voltage
- 6 kV (1.2/50 µs)
- Pollution severity
- 2
- Protection degree
- IP20
- Rated voltage
- 300 V
- Surge voltage category
- III
Load Side
- Continuous current
- 10 A
- Rated switching voltage
- 250 V AC
Rated Data Ul
- Ambient temperature (operational), max.
- 60 °C
- Certificate No. (cURus)
- E223759
- Connection cross-section AWG, max.
- AWG 14
- Connection cross-section AWG, min.
- AWG 26
- Pollution severity level
- 2
- Type of conductor
- rigid copper conductor, flexible copper conductor
Temperatures
- Operating temperature
- -40 °C...60 °C
- Operating temperature, max.
- 60 °C
- Operating temperature, min.
- -40 °C
- Storage temperature
- -40 °C...85 °C
- Storage temperature, max.
- 85 °C
- Storage temperature, min.
- -40 °C
