Weidmuller 1044400000

Additional Technical Data

• Installation advice
  • Direct mounting
• Open sides
  • closed
• Type of mounting
  • Plugged

Approvals

• Approvals
  • GERMLLOYD
  • CCSAUS
  • KEMAKEUR
  • DETNORVER
  • EAC
  • CURUS
• ROHS
  • Conform
• UL File Number Search
  • E60693

Classifications

• eClass 6.2
  • 27-14-92-14
• eClass 7.1
  • 27-14-03-05
• eClass 8.1
  • 27-14-11-51
• eClass 9.0
  • 27-14-11-51
• eClass 9.1
  • 27-14-11-92
• ETIM 3.0
  • EC000897
• ETIM 4.0
  • EC000897
• ETIM 5.0
  • EC000897
• ETIM 6.0
  • EC002848
• UNSPSC
  • 30-21-18-01

Conductors For Clamping (Rated Connection)

• Blade size
  • 0.6 x 3.5 mm
• Clamping range, rated connection, max.
  • 4 mm²
• Clamping range, rated connection, min.
  • 0.13 mm²
• Connection direction
  • top
• Cross-section for connected conductor, finely stranded with wire-end ferrules and plastic collars DIN 46228/4, rated connection, min.
  • 0.5 mm²
• Number of connections
  • 25
• Stripping length
  • 10 mm
• Type of connection
  • Plug-in connection
• Wire connection cross section AWG, max.
  • AWG 26
• Wire connection cross section AWG, min.
  • AWG 12
• Wire connection cross section, finely stranded, max.
  • 4 mm²
• Wire connection cross-section, finely stranded, min.
  • 0.5 mm²
• Wire connection cross-section, finely stranded with wire-end ferrules and plastic collars DIN 46228/4, rated connection, max.
  • 2.5 mm²
• Wire connection cross section, finely stranded with wire-end ferrules DIN 46228/1, rated connection, max.
  • 2.5 mm²
• Wire connection cross section, finely stranded with wire-end ferrules DIN 46228/1, rated connection, min.
  • 0.5 mm²
• Wire connection cross section, solid core max. rated connection
  • 4 mm²
• Wire connection cross section, solid core, min. rated connection
  • 0.5 mm²

Csa Rating Data

• Certificate number (cCSAus)
  • 154685-1460993
• Current size C (cCSAus)
  • 20 A
• Current size D (cCSAus)
  • 5 A
• Voltage size C (cCSAus)
  • 300 V
• Voltage size D (cCSAus)
  • 600 V
• Wire cross section max. (cCSAusX)
  • 12 AWG
• Wire cross section min. (cCSAusX)
  • 26 AWG

Dimensions And Weights

• Depth
  • 41 mm
• Depth (inches)
  • 1.614 inch
• Height
  • 23 mm
• Height (inches)
  • 0.906 inch
• Net weight
  • 92.8 g
• Width
  • 127.5 mm
• Width (inches)
  • 5.02 inch

General Ordering Data

• Available until
  • 2018-03-28
• Delivery status
  • This article will no longer be available in the future.
• GTIN (EAN)
  • 4032248776566
• Order No.
  • 1044400000
• Qty.
  • 10 pc(s).
• Type
  • ZP 2.5/1AN/QV/25
• Version
  • Z-series, Plug-in connector, Direct mounting

Material Data

• Colour
  • Dark Beige
• Material
  • Wemid
• UL 94 flammability rating
  • V-0

Rating Data

• Current at maximum wires
  • 24 A
• Max. voltage of clamp support & pluggable system
  • 690 V
• Rated cross-section
  • 2.5 mm²
• Rated current
  • 24 A
• Rated impulse withstand voltage
  • 6 kV
• Rated impulse withstand voltage to adjacent terminal
  • 6 kV
• Rated voltage
  • 500 V
• Rated voltage to adjoining terminal
  • 500 V
• Volume resistance according to IEC 60947-7-x
  • 33.25 mΩ

System Specifications

• End cover plate required
  • No
• Levels cross-connected internally
  • No
• Mounting rail
  • none
• No. of clamping points per level
  • 1
• Number of levels
  • 1
• PE connection
  • No
• Version
  • Set of connectors, Cross-connector, pluggable, Tension-clamp connection

Temperatures

• Continuous operating temp., max.
  • 120 °C
• Continuous operating temp., min.
  • -50 °C

Ul Rating Data

• Certificate No. (cURus)
  • E60693
• Conductor size Factory wiring max. (cURus)
  • 12 AWG
• Conductor size Factory wiring min. (cURus)
  • 26 AWG
• Conductor size Field wiring max. (cURus)
  • 12 AWG
• Conductor size Field wiring min. (cURus)
  • 26 AWG
• Current size C (cURus)
  • 20 A
• Current size D (cURus)
  • 5 A
• Voltage size C (cURus)
  • 300 V
• Voltage size D (cURus)
  • 600 V
