Weidmuller 1031800000
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Weidmuller 1031800000 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Additional Technical Data
- Installation advice
- Direct mounting
- Open sides
- closed
- Type of mounting
- Snap-on
Approvals
- Approvals
- UR
- CURUSEX
- KEMAKEUR
- EAC
- CSA
- CSAEX
- MARITREG
- GERMLLOYD
- NEMKO
- CE
- IECEXKEM
- ROHS
- Conform
- UL File Number Search
- E60693
Classifications
- eClass 6.2
- 27-14-11-20
- eClass 7.1
- 27-14-11-20
- eClass 8.1
- 27-14-11-20
- eClass 9.0
- 27-14-11-20
- eClass 9.1
- 27-14-11-20
- ETIM 3.0
- EC000897
- ETIM 4.0
- EC002020
- ETIM 5.0
- EC002020
- ETIM 6.0
- EC000897
Conductors For Clamping (Rated Connection)
- 2 x cable lugs DIN 46 234
- 2.5...70 mm²
- 2 x cable lugs DIN 46 235
- 16...70 mm²
- Cable lug to DIN 46234
- 2.5...95 mm²
- Cable lug to DIN 46235
- 16...70 mm²
- Clamping range, rated connection, max.
- 95 mm²
- Clamping range, rated connection, min.
- 2.5 mm²
- Number of connections
- 2
- Stud size for spade connection
- M 8
- Tightening torque, max.
- 12 Nm
- Tightening torque, min.
- 6 Nm
- Type of connection
- Threaded stud connection
Csa Rating Data
- Certificate No. (CSA)
- 200039-1244019
- Current size C (CSA)
- 170 A
- Voltage size C (CSA)
- 600 V
- Wire cross section max. (CSA)
- 00 AWG
- Wire cross section min. (CSA)
- 14 AWG
Dimensions
- Depth
- 62.5 mm
- Depth (inches)
- 2.461 inch
- Height
- 132 mm
- Height (inches)
- 5.197 inch
- Net weight
- 171 g
- TS 35 offset
- 66 mm
- Width
- 32 mm
- Width (inches)
- 1.26 inch
Dimensions And Weights
- Depth
- 62.5 mm
- Depth (inches)
- 2.461 inch
- Height
- 132 mm
- Height (inches)
- 5.197 inch
- Net weight
- 171 g
- Width
- 32 mm
- Width (inches)
- 1.26 inch
General Ordering Data
- Alternative product
- 1028400000
- Available until
- 2017-07-31
- Delivery status
- This article will no longer be available in the future.
- GTIN (EAN)
- 4008190071479
- Order No.
- 1031800000
- Qty.
- 10 pc(s).
- Type
- WFF 70/32
- Version
- Bolt-type screw terminals, Feed-through terminal, Rated cross-section: 70 mm², Threaded stud connection, Direct mounting
Material Data
- Colour
- Dark Beige
- Material
- Wemid
- UL 94 flammability rating
- V-0
Rating Data
- ATEX certificate
- IECEXKEM07.0053U
- KEMA98ATEX1684U_e.pdf
- Certificate No. (ATEX)
- KEMA98ATEX1684U
- Certificate No. (IECEX)
- IECEXKEM07.0053U
- Current (ATEX)
- 167 A
- Current (IECEX)
- 167 A
- Ex 2014/34/EU label
- II 2 G D
- IEC Ex certificate
- IECEXKEM07.0053U_e.pdf
- Max. voltage (ATEX)
- 1100 V
- Max. voltage (IECEX)
- 1100 V
- Operating temperature range
- For operating temperature range see EC Design Test Certificate / IEC Ex-Certificate of Conformity
- Rated cross-section
- 70 mm²
- Rated current
- 192 A
- Rated voltage
- 1,000 V
- Voltage, cross-connection
- CrossConnectionGuide.pdf
- Wire cross section max. (ATEX)
- 70 mm²
- Wire cross section max. (IECEX)
- 70 mm²
Rating Data Iecex/Atex
- ATEX certificate
- IECEXKEM07.0053U
- KEMA98ATEX1684U_e.pdf
- Certificate No. (ATEX)
- KEMA98ATEX1684U
- Certificate No. (IECEX)
- IECEXKEM07.0053U
- Current (ATEX)
- 167 A
- Current (IECEX)
- 167 A
- Ex 2014/34/EU label
- II 2 G D
- IEC Ex certificate
- IECEXKEM07.0053U_e.pdf
- Max. voltage (ATEX)
- 1100 V
- Max. voltage (IECEX)
- 1100 V
- Operating temperature range
- For operating temperature range see EC Design Test Certificate / IEC Ex-Certificate of Conformity
- Voltage, cross-connection
- CrossConnectionGuide.pdf
- Wire cross section max. (ATEX)
- 70 mm²
- Wire cross section max. (IECEX)
- 70 mm²
Safety Note
- Safety notice
- Safety Information
System Specifications
- Levels cross-connected internally
- No
- Mounting rail
- TS 35
- No. of clamping points per level
- 2
- Number of levels
- 1
- PE connection
- No
Temperatures
- Continuous operating temp., max.
- 120 °C
- Continuous operating temp., min.
- -50 °C
Ul Rating Data
- Certificate No. (UR)
- E60693
- Conductor size Factory wiring max. (UR)
- 00 AWG
- Conductor size Factory wiring min. (UR)
- 14 AWG
- Conductor size Field wiring max. (UR)
- 00 AWG
- Conductor size Field wiring min. (UR)
- 14 AWG
- Current size C (UR)
- 175 A
- Voltage size C (UR)
- 1000 V
