WAGO 858-517
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Relay module; Nominal input voltage: 115 VAC; 4 changeover contacts; Limiting continuous current: 5 A; with gold contacts; with manual operation; Red status indicator; Module width: 31 mm
WAGO 858-517 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Commercial Data
- Country of origin
- DE
- Customs tariff number
- 85364900990
- GTIN
- 4055143567855
- Packaging type
- Box
Connection Data
- Connection technology
- Push-in CAGE CLAMP®
- Fine-stranded conductor
- 0.34 … 1.5 mm² / 22 … 16 AWG
- Note (conductor cross-section)
- 2 x 0.34 … 2 x 1.5 mm² / 1 x 2.5 mm² / 2 x 22 … 2 x 16 AWG
- Solid conductor
- 0.34 … 1.5 mm² / 22 … 16 AWG
- Strip length
- 9 … 10 mm / 0.35 … 0.39 inches
Control Circuit
- Input voltage range
- -20 … +10 %
- Nominal input current at UN
- 10 mA
- Nominal input voltage UN
- AC 115 V
Environmental Requirements
- Ambient temperature (operation at UN)
- -25 … +70 °C
- Ambient temperature (storage)
- -40 … +70 °C
- Operating altitude (max.)
- 2000 m
- Processing temperature
- -25 … +50 °C
- Relative humidity
- 5 … 85 %
- Temperature range of connection cable
- ≥ (Tambient + 25 K)
Load Circuit
- Bounce time (typ.)
- 4 ms
- Contact material (relay)
- AgCe + Au
- Drop-out time (typ.)
- 35 ms
- Electrical life (NO; resistive load; 23 °C)
- 100 x 10³ switching operations
- Inrush current (resistive) max.
- (AC) 15 A / 4 s
- Limiting continuous current
- 5 A
- Mechanical life
- 20 x 10⁶ switching operations
- Number of changeover/switchover contacts
- 4
- Pull-in time (typ.)
- 25 ms
- Recommended minimum load
- 5 V / 1 mA / 50 mW
- Switching capacity
- AC-15: 1 A / AC 240 V; DC-13: 2 A / DC 24 V
- Switching power (resistive) max.
- AC 1250 VA; DC (see load limit curve)
- Switching voltage (max.)
- AC 250 V
Material Data
- Fire load
- 1.255 MJ
- Weight
- 95.300 g
Mechanical Data
- Mounting position
- Horizontal (standing/lying); vertical
- Mounting type
- DIN-35 rail
Notes
- Note
- To prevent damaging the gold layer, 30 VDC switching voltages and 50 mA currents must not be exceeded. Higher switching power eventually evaporates the gold layer. The resulting deposits in the housing may reduce service life.
Physical Data
- Depth from upper-edge of DIN-rail
- 73 mm / 2.874 inches
- Height
- 97 mm / 3.819 inches
- Width
- 31 mm / 1.22 inches
Safety And Protection
- Dielectric strength (control/load circuit) (AC, 1 min)
- 1.5 kVrms
- Dielectric strength (load/load circuit) (AC, 1 min)
- 1.5 kVrms
- Dielectric strength (open contact) (AC, 1 min)
- 1 kVrms
- Insulation type (adjacent devices)
- Reinforced insulation (safe isolation)
- Insulation type (control/load circuit)
- Basic insulation
- Insulation type (load/load circuit)
- Basic insulation
- Insulation type (open contact)
- Functional insulation
- Overvoltage category
- II
- Pollution degree
- 2
- Protection type
- IP20
- Rated surge voltage
- 2.5 kV
- Rated voltage
- 300 V
Signaling
- Status indicator
- Red LED || Mechanical
Specifications
- Product Group Code
- 0006
Standards And Specifications
- Standards/specifications
- EN 61010-2-201 || EN 61810-1 || EN 61373 || UL 508 (max. 50 °C)
