WAGO 757-343
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
M8 sensor/actuator box; 4-way; 3-pole; M16 connector
WAGO 757-343 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Commercial Data
- Country of origin
- DE
- Customs tariff number
- 85366990990
- GTIN
- 4044918978675
- Packaging type
- Box
Connection Data
- Connection technology: inputs/outputs
- 4 x M8 socket; 3-pole
- Connection technology: trunk cable
- 1 x M16 plug; 14-pole
Environmental Requirements
- Ambient temperature (operation)
- -25 … +80 °C
- Note on protection type
- Per EN 60529 (NEMA 6 & 6P) in fully locked position with its plugs or protective caps
- Pollution degree
- 3 per VDE 0110
- Protection type
- IP67
- Shock resistance
- Per IEC 60068-2-27
- Vibration resistance
- Per IEC 60068-2-6
Material Data
- Encapsulation
- Fully encapsulated with conformal coating (UL 94 V0)
- Housing material
- PA 66 (UL 94 V0); RAL 7035; silicon and halogen free
- Material properties of the connections
- Contact: CuSn, nickel base-coat plating and 0.8 μm gold-plated; Threaded bush: die-cast Zn, nickel-plated; Seal: Viton; 50 mating cycles
Mechanical Data
- Mounting type
- Screw mount
- Weight
- 110.000 g
Physical Data
- Depth
- 117 mm / 4.606 inches
- Height
- 26 mm / 1.024 inches
- Width
- 30 mm / 1.181 inches
Specifications
- Product Group Code
- 0023
Technical Data
- Contact resistance (max.)
- 0.01 Ω
- Current carrying capacity (signal connections)
- 2 A
- Current carrying capacity (supply connections)
- 6 A
- Functionally separated potential groups
- Kontakt/Kontakt
- Indicators
- LED yellow: Signal status (1 x per contact); LED (U) green: Sensor/actuator box status
- Insulation resistance
- 1000 MΩ
- Rated value of electrical isolation
- 500 V
- Signal characteristics
- PNP
- Supply voltage
- 10 … 30 VDC; Rated voltage: 32 V ~ rms
