WAGO 750-940
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
EnOcean-RS-485-Gateway; 868 MHz
WAGO 750-940 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Commercial Data
- Country of origin
- DE
- Customs tariff number
- 84733080000
- GTIN
- 4066966154894
Connection Data
- Connection technology: antenna
- 1 x SMA socket for external antenna
- Connection technology: communication/fieldbus
- 1 x RS-485 connection: 5-pole 2-conductor compact PCB connectors with PUSH WIRE® (252-155 is included)
- Connection technology: supply
- 1 x 2-pole, 2-conductor compact PCB connectors with PUSH WIRE® (252-152 is included)
- Connection type 1
- Kommunikation
- Connection type 2
- Power supply
- Solid conductor
- 0.4 … 0.8 mm² / 26 … 20 AWG
- Solid conductor 2
- 0.4 … 0.8 mm² / 26 … 20 AWG
- Strip length
- 6 … 7 mm / 0.24 … 0.28 inches
- Strip length 2
- 6 … 7 mm / 0.24 … 0.28 inches
Environmental Requirements
- Ambient temperature (operation)
- 0 … +55 °C
- Ambient temperature (storage)
- -20 … +85 °C
- EMC emission of interference
- Per EN 61000-6-3 + A1
- EMC immunity to interference
- Per EN 61000-6-2
- Pollution degree
- 2 per EN 60664-1, EN 61131-2
- Protection type
- IP30
Material Data
- Conformity marking
- CE
- Fire load
- 0.000 MJ
- Weight
- 97.000 g
Physical Data
- Diameter
- 95 mm
- Height
- 36 mm / 1.417 inches
Specifications
- Product Group Code
- 0015
Technical Data
- Antenna
- Internal (external antenna optional via SMA socket)
- Baud rate
- 9.6 kBd … 115.2 kBd
- Communication
- RS-485 interface
- Data width
- 50 bytes
- Device-specific
- Number of devices connected in a series in Modbus mode: Max. 10; ESP3 mode: 1:1 connection
- Frequency band
- 868 MHz
- Overvoltage category
- III
- Radio technology
- EnOcean
- Supply voltage
- 24 VDC (18 … 31.2 V)
- Transmission range
- Approx. 30 m within buildings; >100 m in open space
