WAGO 704-3004
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Interface module for system wiring; for 232 Series Pluggable Connectors; 2 x 10-pole; 16-channel digital input or output; 2-wire connection; Double-deck PCB terminal blocks; for higher voltages; in mounting carrier
WAGO 704-3004 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Commercial Data
- Country of origin
- FR
- Customs tariff number
- 85369010000
- GTIN
- 4050821220541
- Packaging type
- Box
Connection 1
- Connection type 1
- System
- Connector
- WAGO 231 Series
- Design
- PCB terminal blocks
- Fine-stranded conductor
- 0.08 … 2.5 mm² / 28 … 12 AWG
- Mating direction
- Vertical
- Note (conductor cross-section)
- 12 AWG: THHN, THWN
- Pole number 1
- 20
- Solid conductor
- 0.08 … 2.5 mm² / 28 … 12 AWG
- Strip length
- 8 … 9 mm / 0.31 … 0.35 inches
- WAGO connector
- WAGO 232 Series
Connection 2
- Connection type 2
- Field
- Design 2
- PCB terminal blocks (double-deck)
- Fine-stranded conductor 2
- 0.08 … 2.5 mm² / 28 … 12 AWG
- Pole number 2
- 32
- Solid conductor 2
- 0.08 … 2.5 mm² / 28 … 12 AWG
- Strip length 2
- 5 … 6 mm / 0.2 … 0.24 inches
- WAGO connector 2
- WAGO 736 Series
Connection 3
- Connection type 3
- Power supply
- Design 3
- PCB terminal blocks
- Fine-stranded conductor 3
- 0.08 … 2.5 mm² / 28 … 12 AWG
- Pole number 3
- 3
- Solid conductor 3
- 0.08 … 2.5 mm² / 28 … 12 AWG
- Strip length 3
- 8 … 9 mm / 0.31 … 0.35 inches
- WAGO connector 3
- WAGO 742 Series
Electrical Data
- Circuit type
- 2-wire connection
- Inputs/outputs
- 16-channel digital input or output
- Internal fuse
- 6.3 A
- Limiting continuous current
- 3 A
- Nominal operating voltage
- AC 230 V
- Operating voltage range
- ±10 %
- Total current
- 8 A
Environmental Requirements
- Ambient temperature (operation)
- -20 … +50 °C
- Ambient temperature (storage)
- -40 … +70 °C
- Relative humidity
- ≤ 85% (non-condensing)
Ge Fanuc
- GE Fanuc 9030
- IC693 MDL240 || IC693 MDL310 || IC693 MDL340 || IC693 MDL390 || IC693 MDL734
Material Data
- Fire load
- 2.872 MJ
- Weight
- 170.000 g
Mechanical Data
- Mounting type
- DIN-35 rail
Physical Data
- Depth from upper-edge of DIN-rail
- 56 mm / 2.204 inches
- Height
- 85 mm / 3.346 inches
- Width
- 111 mm / 4.37 inches
Rockwell
- Rockwell Compact Logix
- 1769 - IA16 || 1769 - IM12 || 1769 - IQ6XOW4 || 1769 - OA16 || 1769 - OW8I || 1769 - OW16
- Rockwell Control Logix
- 1756 - IA16I || 1756 - IB16ISOE || 1756 - IH16I || 1756 - IM16I || 1756 - OA16I || 1756 - OH8I || 1756 - OW16I || 1756 - OX8I
Safety And Protection
- Rated surge voltage
- 2 kV
- Rated voltage
- 250 V
Schneider
- Schneider Modicon M340
- BMX DAI 1602 || BMX DAI 1603 || BMX DAI 1604 || BMX DAO 1605 || BMX DDI 1603 || BMX DRA 0805 || BMX DRA 1605
- Schneider Modicon Quantum
- 140 DAI 340 00 || 140 DAI 353 00 || 140 DAI 440 00 || 140 DAI 453 00 || 140 DAI 540 00 || 140 DAI 543 00 || 140 DAI 553 00 || 140 DAI 740 00 || 140 DAI 753 00 || 140 DAO 840 00 || 140 DAO 840 10 || 140 DRA 840 00
- Schneider TSX
- TSX DEY 16A2 || TSX DEY 16A3 || TSX DEY 16A4 || TSX DEY 16A5 || TSX DEY 16D3 || TSX DSY 08R4 || TSX DSY 08R5 || TSX DSY 08R5A || TSX DSY 16R5 || TSX DSY 16S4 || TSX DSY 16S5
Siemens
- Siemens S7-1500
- 6ES7 521-1FH00-0AA0 || 6ES7 521-7EH00-0AB0 || 6ES7 522-5EH00-0AB0 || 6ES7 522-5FF00-0AB0 || 6ES7 522-5FH00-0AB0 || 6ES7 522-5HF00-0AB0 || 6ES7 522-5HH00-0AB0
- Siemens S7-300
- 6ES7 321-1CH00-0AA0 || 6ES7 321-1CH20-0AA0 || 6ES7 321-1CH80-0AA0 || 6ES7 321-1EL00-0AA0 || 6ES7 321-1FH00-0AA0 || 6ES7 322-1FH00-0AA0 || 6ES7 322-1FL00-0AA0 || 6ES7 322-1HF10-0AA0 || 6ES7 322-1HH01-0AA0 || 6ES7 322-5GH00-0AB0
- Siemens S7-400
- 6ES7 422-1HH00-0AA0
Specifications
- Product Group Code
- 0030
