WAGO 286-807

Commercial Data

• Country of origin
  • DE
• Customs tariff number
  • 85369010000
• GTIN
  • 4045454198084
• Packaging type
  • Box

Electrical Data

• Operating voltage
  • ≤ AC/DC 250 V
• Peak reverse voltage
  • 1000 V
• Rectified current for each diode (resistive)
  • 1 A || 1 A

Environmental Requirements

• Ambient temperature (operation)
  • -25 … +40 °C
• Operating altitude (max.)
  • 2000 m
• Relative humidity
  • 5 … 95 % (no condensation permissible)

Material Data

• Color
  • Gray
• Fire load
  • 0.413 MJ
• Weight
  • 23.000 g

Mechanical Data

• Housing design
  • Plug for carrier terminal blocks
• Mounting type
  • Pluggable module for receptacle terminal blocks

Notes

• Note
  • Max. admissible forward current per the manufacturer’s data sheet. With all diodes loaded, the continuous current must be reduced to 0.45 A.

Physical Data

• Depth
  • 52 mm / 2.047 inches
• Height from upper-edge of DIN-rail
  • 82.5 mm / 3.25 inches
• Width
  • 20 mm / 0.787 inches

Safety And Protection

• Pollution degree
  • 2
• Rated surge voltage
  • 4 kV
• Rated voltage
  • 250 V

Specifications

• Product Group Code
  • 0006
