SICK 1015798
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
SICK 1015798 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Ambient Data
- Ambient Operating Temperature
- –25 °C +55 °C
- Ambient Storage Temperature
- –20 °C +70 °C
- EMC
- EN 60947-5-2
- Protection Class
- II
- Shock load
- 10 g / DIN EN 60068-2-29 / 16 ms
- Vibration Resistance
- 5 g, 10 Hz ... 55 Hz (IEC 68-2-6)
Classifications
- ECl@ss 5.0
- 27270910
- ECl@ss 5.1.4
- 27270910
- ECl@ss 6.0
- 27270910
- ECl@ss 6.2
- 27270910
- ECl@ss 7.0
- 27270910
- ECl@ss 8.0
- 27270910
- ECl@ss 8.1
- 27270910
- ECl@ss 9.0
- 27270910
- ETIM 5.0
- EC002549
- ETIM 6.0
- EC002549
- UNSPSC 16.0901
- 39121528
Features
- Beam Separation
- 12.5 mm
- Detection Height
- 87.5 mm
- Minimum Detectable Object (MDO)
- Parallel beam, 6 mm ... 12.5 mm
- Number of Beams
- 8
- Resolution (adjustable)
- 6 mm ... 12.5 mm (Dependence of the range)
- Technology
- Retro-reflective light grid
Interfaces
- Connection Type
- Male connector M12, 5-pin
- Switching Output
- 2 x PNP (Q / Ǭ.)
Mechanics/Electronics
- Circuit Protection
- UV connections, reverse polarity protected, Output Q short-circuit protected, Interference pulse suppression
- Dimensions (W x H x D)
- 62 mm x 106 mm x 46.6 mm
- Enclosure Rating
- IP 67
- Front screen
- PMMA
- Housing Material
- Plastic
- Indication
- LED
- Initialization Time
- 0.6 s
- Output Current IMax.
- ≤ 100 mA
- Output Load Capacitive
- 100 nF
- Output Load Inductive
- 1 H
- Output Mode
- Q dark switching (Q = active, if at least one beam is interrupted, /Q = active, if all of the beams are free)
- Power Consumption Sender
- 80 mA
- Ripple
- < 5 Vpp
- Supply Voltage Vs
- DC 18 V ... 30 V (Typical value)
- Teach-in Input
- PNP
- Wave Length
- 650 nm
- Weight
- 230 g
Performance
- Maximum Range
- 1.5 m
- Minimum Range
- ≥ 100 mm
- Operating Range
- 1.5 m
- Response Time
- Parallel beam 0.6 ms (With resistive load)
