Description
Complete body for pilot lights, Harmony XB6, green light block with body/fixing collar with integral LED 12...24 V
Schneider Electric ZB6EB3A is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Complementary
- Current Consumption
- 15 mA
- Net Weight
- 0.003 kg
- Operating Position
- any position
- Signalling Type
- steady
- Supply Voltage Limits
- 6-30 V AC/DC
- Surge Withstand
- 1 kV in contact IEC 61000-4-5 || 2 kV in free air IEC 61000-4-5
- [Uimp] Rated Impulse Withstand Voltage
- 4 kV IEC 60947-1
- [Ui] Rated Insulation Voltage
- 250 V 3)IEC 60947-1
Contractual warranty
- Warranty
- 18 months
Environment
- Ambient Air Temperature For Operation
- -25-70 °C
- Ambient Air Temperature For Storage
- -40-70 °C
- Electrical Shock Protection Class
- class II IEC 61140
- Electromagnetic Emission
- class B IEC 55011
- Product Certifications
- UL || GOST || CSA || CCC
- Protective Treatment
- TC
- Resistance To Electromagnetic Fields
- 10 V/m IEC 61000-4-3
- Resistance To Electrostatic Discharge
- 6 kV on contact (on metal parts) IEC 61000-2-6 || 8 kV in free air (in insulating parts) IEC 61000-2-6
- Resistance To Fast Transients
- 2 kV IEC 61000-4-4
- Shock Resistance
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
- Standards
- JIS C 852 || IEC 60947-5-5 || JIS C 4520 || UL 508 || CSA C22.2 No 14 || IEC 60947-5-1 || IEC 60947-1
- Vibration Resistance
- +/- 3 mm 2-500 Hz)IEC 60068-2-6 || 5 gn 2-500 Hz)IEC 60068-2-6
Offer Sustainability
- California Proposition 65
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- China Rohs Regulation
- X
- Eu Rohs Directive
- Pro-active compliance (Product out of EU RoHS legal scope)
- Mercury Free
- Yes
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
- Rohs Exemption Information
- Yes
- Weee
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Specifications
- Bulb Base
- integral LED
- Connections - Terminals
- pins for printed circuit board 1 x 0.5 mm
- Device Short Name
- ZB6
- Light Block Supply
- direct
- Light Source
- LED
- Light Source Colour
- green
- Product Or Component Type
- complete body for pilot lights
- Range Of Product
- Harmony XB6
- Sale Per Indivisible Quantity
- 5
- [Us] Rated Supply Voltage
- 12...24 V AC/DC
