Schneider Electric ZB6E2B
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
This Harmony ZB6E2B is a single contact block for head, 1 NC faston connector. It is part of the range Harmony XB6 diameter 16mm monolithic plastic push buttons, switches, and pilot lights.Contact block, Harmony XB6, single contact, for head 16mm, silver alloy, faston connector, 1NC
Schneider Electric ZB6E2B is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Complementary
- Electrical Durability
- 1000000 cycles, AC-15 230 V 3600 cyc/h 0.5 EN/IEC 60947-5-1 appendix C || 1000000 cycles, DC-13 230 V 3600 cyc/h 0.5 EN/IEC 60947-5-1 appendix C
- Electrical Reliability
- λ = 10exp(-8) 5 V 1 mA with confidence level of 90 % EN/IEC 60947-5-4
- [Ie] Rated Operational Current
- 3 A 120 V, AC-15, B300 || 1.5 A 240 V, AC-15, B300 || 0.1 A 250 V, DC-13, R300 || 0.22 A 125 V, DC-13, R300
- Mechanical Durability
- 5000000 cycles
- Net Weight
- 0.004 kg
- Operating Force
- 2.5 N NC changing electrical state
- Operating Travel
- 1 mm NC changing electrical state) || 3.5 mm total travel)
- Positive Opening
- with EN/IEC 60947-5-1 appendix K
- Short-Circuit Protection
- 6 A cartridge fuse gG
- Terminals Description Iso N°1
- (1-2)NC
- [Uimp] Rated Impulse Withstand Voltage
- 4 kV EN/IEC 60947-1
- [Ui] Rated Insulation Voltage
- 250 V 3)EN/IEC 60947-1
Contractual warranty
- Warranty
- 18 months
Environment
- Ambient Air Temperature For Operation
- -25-70 °C
- Ambient Air Temperature For Storage
- -40-70 °C
- Ip Degree Of Protection
- IP20 IEC 60529
- Product Certifications
- GOST || CSA || UL || CCC
- Protective Treatment
- TC
- Shock Resistance
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
- Standards
- UL 508 || JIS C 4520 || EN/IEC 60947-5-1 || JIS C 852 || EN/IEC 60947-1 || EN/IEC 60947-5-4 || CSA C22.2 No 14
- Vibration Resistance
- +/- 3 mm 2-500 Hz)IEC 60068-2-6 || 5 gn 2-500 Hz)IEC 60068-2-6
Offer Sustainability
- California Proposition 65
- WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- China Rohs Regulation
- X
- Circularity Profile
- ENVEOLI1710010EN
- Environmental Disclosure
- ENVPEP1710010EN
- Eu Rohs Directive
- Pro-active compliance (Product out of EU RoHS legal scope)
- Mercury Free
- Yes
- Reach Free Of Svhc
- Yes
- Reach Regulation
- Free of Substances of Very High Concern above the threshold
- Rohs Exemption Information
- Yes
- Sustainable Offer Status
- Green Premium product
- Toxic Heavy Metal Free
- Yes
- Weee
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Specifications
- Connections - Terminals
- Faston connector
- Contact Block Type
- single
- Contact Operation
- slow-break
- Contacts Material
- silver alloy (Ag/Ni)
- Contacts Type And Composition
- 1 NC
- Device Short Name
- ZB6
- Product Or Component Type
- contact block
- Range Of Product
- Harmony XB6
- Sale Per Indivisible Quantity
- 10
