Schneider Electric XDPC5555C4

Complementary

• Contacts Type And Composition
  • 4 C/O
• Contacts Usage
  • standard
• Depth
  • 65 mm
• Height
  • 166.6 mm
• Mechanical Durability
  • 1000000 cycles
• Net Weight
  • 0.5 kg
• Operator Direction Information
  • 1 direction
• Operator Position Information
  • 2 positions
• Return
  • spring return
• Width
  • 52 mm

Contractual warranty

• Warranty
  • 18 months

Environment

• Ambient Air Temperature For Operation
  • -40-60 °C
• Ip Degree Of Protection
  • IP65
• Standards
  • UL 508 || EN/IEC 60947-5-4 || EN/IEC 60947-1 || CSA C22.2 No 14 || EN/IEC 60947-5-5 || EN/IEC 60947-5-1 || JIS C 4520

Offer Sustainability

• California Proposition 65
  • WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
• China Rohs Regulation
  • X
• Circularity Profile
  • ENVEOLI1310004EN
• Environmental Disclosure
  • ENVPEP1310004EN
• Eu Rohs Directive
  • Pro-active compliance (Product out of EU RoHS legal scope)
• Mercury Free
  • Yes
• Reach Regulation
  • Reference contains Substances of Very High Concern above the threshold
• Rohs Exemption Information
  • Yes
• Sustainable Offer Status
  • Green Premium product

Specifications

• Bezel Material
  • plastic
• Device Short Name
  • XDP
• Mounting Diameter
  • 48 mm
• Product Or Component Type
  • complete joystick controller
• Range Of Product
  • Harmony XK
• Sale Per Indivisible Quantity
  • 1
