Schneider Electric VZ1L018UM20
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
This line choke can be used to provide improved protection against overvoltages on the line supply. It can also be used to reduce harmonic distortion of the current produced by the drive. This product is compliant with IEC 61800-5-1 (VDE 0160 level 1 high-energy overvoltages on the line supply). Its rated current is equal to 18A and its value of inductance to 2mH. It is compatible with Altivar 31, Altivar 32, Altivar 312, Altivar machine ATV320, Lexium 05 and Lexium 32.line choke - 2 mH - 18 A - 1 phase - 30 W - for variable speed drive
Schneider Electric VZ1L018UM20 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Complementary
- Depth
- 105 mm
- Height
- 120 mm
- Maximum Voltage Drop At Rated Load
- 5 %
- Net Weight
- 1.99 kg
- Supply Frequency
- 50...60 Hz
- Width
- 85 mm
Contractual warranty
- Warranty
- 18 months
Environment
- Ip Degree Of Protection
- choke IP00 || terminals IP20
- Standards
- VDE 0160 level 1 || IEC 60076 (with HD398) || EN 50178
Offer Sustainability
- California Proposition 65
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- China Rohs Regulation
- X
- Eu Rohs Directive
- Pro-active compliance (Product out of EU RoHS legal scope)
- Mercury Free
- Yes
- Reach Free Of Svhc
- Yes
- Reach Regulation
- Free of Substances of Very High Concern above the threshold
- Rohs Exemption Information
- Yes
- Toxic Heavy Metal Free
- Yes
Specifications
- Device Application
- reduction of current harmonics
- Line Rated Current
- 18 A
- Phase
- single phase
- Product Compatibility
- ATV312HU11M2 - line choke - 1 per drive || ATV312HU15M2 - line choke - 1 per drive || ATV312HU22M2 - line choke - 1 per drive || ATV31CU11M2 - line choke - 1 per drive || ATV31CU15M2 - line choke - 1 per drive || ATV31CU22M2 - line choke - 1 per drive || ATV32HU11M2 - line choke - 1 per drive || ATV32HU15M2 - line choke - 1 per drive || ATV32HU22M2 - line choke - 1 per drive || LXM05D17F1 - line choke - 1 per drive || LXM05D17M2 - line choke - 1 per drive || LXM05D28F1 - line choke - 1 per drive || LXM05D28M2 - line choke - 1 per drive || LXM32.D18M2 - line choke - 1 per drive || LXM32.D30M2 - line choke - 1 per drive || LXM32.U90M2 - line choke - 1 per drive || variable speed drive ATV320 1.1 kW 200...240 V - single phase - line choke - 1 per drive || variable speed drive ATV320 1.5 kW 200...240 V - single phase - line choke - 1 per drive || variable speed drive ATV320 2.2 kW 200...240 V - single phase - line choke - 1 per drive
- Product Or Component Type
- line choke
- Range Compatibility
- Altivar 312 Solar || Lexium 32 || Altivar 312 || Altivar 31C || Lexium 05 || Altivar Machine ATV320 || Altivar 32
- Range Of Product
- Altivar
- Thermal Losses
- 30 W
- Value Of Inductance
- 2 mH
