Schneider Electric TM5CSLC200FS
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
This product is part of the Modicon TM5 range, an High-Performance and Safe IP20 Modular I/O System. This safe logic controller has Intel Xscale 266MHz processor with reverse polarity protection, and a 24 V DC power supply. The controller has integrated fuse (not interchangeable) input protection with fanless cooling. It offers SERCOS 3 (Ethernet) communication network with 100Mbps data transmission rate for the full duplex bus length, with 2 integrated shielded RJ45 ports. It supports maximum 100 safety nodes with 2 internal switches. It reaches Category 4 of safety level conforming to EN ISO 13849, and SIL 3 safety integrity level according to IEC 62061. It is an IP20 rated product. The housing colour is red. Its dimensions are 87.5mm (width) x 75mm (depth) x 99mm (height). It weighs 0.29kg. The Modicon TM5 meets the typical requirements of production and packaging machinery, as well as material handling and assembly systems. This product is certified by GOST-R, C-Tick, cULus and CSA. It meets IEC 61131-2, UL 508, CSA C22.2 No 213 and CSA C22.2 No 142 standards. This product is compatible with motion controller, communicating on Sercos 3 fieldbus. It is installed by mounting on a 35mm DIN rail. This modular IO system provides a flexible and scalable configuration of remote or distributed IO islands by connection with Modicon and PacDrive 3 controllers. Flexible and scalable, designed for complex machines.Controller system, Modicon TM5, Safe logic CPU plus, SERCOS 3 interface, 80 nodes
Schneider Electric TM5CSLC200FS is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Complementary
- Color
- Red
- Communication Network Type
- SERCOS III Ethernet)
- Cycle Time
- 1 ms
- Depth
- 75 mm
- Function Available
- support of 32 machine options || with 2 internal switch || support max 100 safety nodes
- Height
- 99 mm
- Input Protection Type
- integrated fuse (not interchangeable)
- Local Signalling
- for application run or SoSafe debug mode 1 LED (green or orange) || for authorization status 1 LED (green) || for configuration status (Ready) 1 LED (orange) || for firmware status 1 LED (orange) || for boot status 4 LEDs (red) || for memory key status 1 LED (orange)
- Marking
- CE
- Maximum Cable Distance Between Devices
- 100 m between station
- Net Weight
- 0.29 kg
- Number Of Devices
- 2 shielded RJ45 || 1 memory key slot
- Power Consumption In W
- 5.1 W
- Rated Voltage
- 24-24 V -15...20 %
- Realtime Clock
- with non-volatile memory
- Safety Level
- SIL 3 IEC 61508 || SIL 3 IEC 62061 || PL = e EN 13849-1
- Safety Reliability Data
- PFD < 1E-5 || PFH < 1E-9 || MTTFd > 100 years
- Transmission Rate
- 100 Mbit/s for full duplex
- Type Of Cooling
- fanless
- Width
- 87.5 mm
Contractual warranty
- Warranty
- 18 months
Environment
- Ambient Air Temperature For Operation
- 0-45 °C vertical installation) || 0-55 °C horizontal installation)
- Ambient Air Temperature For Storage
- -25-70 °C
- Ip Degree Of Protection
- IP20
- Operating Altitude
- 0...6561.68 ft (0...2000 m)
- Product Certifications
- cULus || GOST-R
- Relative Humidity
- 5-95 % without condensation
- Standards
- IEC 62061 || EN 13849-1 || IEC 61508 || IEC 61131-2 || IEC 61511
Offer Sustainability
- California Proposition 65
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- China Rohs Regulation
- X
- Circularity Profile
- ENVEOLI2203008EN
- Environmental Disclosure
- ENVPEP2203008EN
- Eu Rohs Directive
- Pro-active compliance (Product out of EU RoHS legal scope)
- Mercury Free
- Yes
- Pvc Free
- Yes
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
- Rohs Exemption Information
- Yes
- Sustainable Offer Status
- Green Premium product
- Toxic Heavy Metal Free
- Yes
- Weee
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Specifications
- Device Application
- safety logic controller
- Processor Name
- Intel Xscale 266 MHz
- Product Or Component Type
- controller system
- Range Of Product
- Modicon TM5
- Reverse Polarity Protection
- yes
