Schneider Electric TCSEGDB23F24FK
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
The Modbus Plus proxy module is part of the Modicon M340 and Modicon M580 ranges, an offer of Programmable Automation Controllers (PAC). This module has 128 slaves, 10/100BASE-T and RS485 physical interfaces. Its conformal coating provides an extra protection for use in harsh environments. This Modbus Plus Proxy module allows PLCs to communicate with existing Modbus Plus devices without the need to modify these devices applications. It features 2 Ethernet TCP/IP - RJ45 for Modbus TCP and 2 Modbus - SUB-D 9 for Modbus plus for integrated connections. Its current consumption is 300 mA at 24V DC external. It shows a white coating. It is suitable for process industries, renewable energies, water, cement, manufacturing, infrastructures and machines applications. It conforms to UL 508, CSA 22.2, cUL, EMI EN 55011, EN 61131-2, and C-Tick specifications. This module is compatible with Modicon M340 Programmable Logic Controllers (PLC). The module is provided with a mounting plate, 2 front-mounted power supply connectors (2 positions). It can be attached either to a rack or to a DIN rail. Compact-shaped, Modicon M340 offers in small box flexibility and integrated functions. In the heart of process, it provides you plug and work solutions with both Schneider Electric and third party devices.Modbus Plus proxy module, Modicon X80, conformal coating
Schneider Electric TCSEGDB23F24FK is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Complementary
- Communication Gateway
- Ethernet Modbus TCP to Modbus Plus
- Communication Service
- Modbus TCP messaging || peer cop dialogue || Modbus Plus messaging || configuration control || diagnostics || Modbus Plus server (scanned by the PLC) || FDR || SNMP network management || read/write variables || Global Data
- Current Consumption
- 300 mA 24 V DC external
- Integrated Connection Type
- 2 Ethernet TCP/IP - RJ45 Modbus TCP || 2 Modbus - SUB-D 9 Modbus Plus
- Method Of Access
- token ring Modbus Plus || CSMA/CD Modbus TCP
- Module Format
- standard
- Number Of Slave
- 128
- Physical Interface
- 10/100BASE-T || RS485
- Product Compatibility
- M340 PLC
- Transmission Rate
- 1 Mbit/s, 450 m Modbus Plus per segment || 1 Mbit/s, 1800 m Modbus Plus with 3 repeaters || 10...100 Mbit/s, 100 m Modbus TCP without repeater
- Transmission Support Medium
- Modbus Plus single twisted pair cable || Modbus TCP category 5 shielded twisted pair (STP)
Environment
- Ambient Air Temperature For Operation
- -25-70 °C
- Ambient Air Temperature For Storage
- -45-85 °C
- Operating Altitude
- <= 6561.68 ft (2000 m)
- Protective Treatment
- conformal coating Humiseal 1A33
- Relative Humidity
- 10-95 % without condensation
Offer Sustainability
- California Proposition 65
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- China Rohs Regulation
- X
- Eu Rohs Directive
- Pro-active compliance (Product out of EU RoHS legal scope)
- Mercury Free
- Yes
- Rohs Exemption Information
- Yes
- Weee
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Specifications
- Product Or Component Type
- Modbus Plus proxy module
- Range Of Product
- Modicon M340 automation platform
- Structure Type
- industrial bus
