Schneider Electric STBXBE1300K
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
This bus extension kit is part of the Modicon STB range, an offer of IP20 modular distributed I/Os on multiple networks and fieldbus. This BOS internal bus extension kit is furnished with 2-pin removable connector for power supply and FireWire for interface. It is a BOS module with rated supply voltage of 24V DC and input current of 400mA. It is an IP20 rated product. It is suitable for packaging, bottling, assembly, distribution, textile, printing and semiconductor machines. This product is certified by CE, FM Class 1 Division 2, CSA, UL. It is compatible with standard STB modules. The kit includes STBXTS1120, 2-terminal screw type connector, STBXBA2300 size 2 base, STBXTS2120, 2-terminal spring clamp connector and STBXBE1300 BOS module. Advantys distributed I/O solutions are simple, open and flexible, meeting needs in every stage of the product life cycle. For distributed connection to sensors and actuators from a PLC with prefabricated cables.bus extension kit, Modicon STB, BOS internal
Schneider Electric STBXBE1300K is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Complementary
- Electrical Connection
- 2 pins for removable connector power supply || Firewire interface
- Input Current
- 400 mA
- Kit Composition
- STBXBE1300 BOS module || STBXTS2120, 2-terminal spring clamp connector || STBXBA2300 size 2 base || STBXTS1120, 2-terminal screw type connector
- Marking
- CE
- Mounting Location
- beginning of extension segment
- Output Voltage
- 5.25 V +/- 0.21 % logic bus
- Output Voltage Type
- DC
- Overvoltage Category
- II
- Power Supply Output Current
- 1.2 A
- Product Compatibility
- standard STB modules
- Supply Circuit Type
- DC
- Supply Voltage Limits
- 19.2-30 V
- [Us] Rated Supply Voltage
- 24 V
Contractual warranty
- Warranty
- 18 months
Environment
- Ambient Air Temperature For Storage
- -40-85 °C
- Electromagnetic Compatibility
- immunity to electromagnetic interference IEC 61131-2
- Ip Degree Of Protection
- IP20 conforming to IEC 61131-2 class 1
- Operating Altitude
- <= 6561.68 ft (2000 m)
- Pollution Degree
- 2 IEC 60664-1
- Product Certifications
- FM Class 1 Division 2 || UL || CSA
- Relative Humidity
- 95-95 % 60-60 °C without condensation
- Shock Resistance
- 30 gn 11 ms IEC 88 reference 2-27
- Vibration Resistance
- 3 gn 58-150 Hz 35 x 7.5 mm symmetrical DIN rail || 5 gn 58-150 Hz 35 x 15 mm symmetrical DIN rail || +/-0.35 mm 10-58 Hz
Offer Sustainability
- California Proposition 65
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- China Rohs Regulation
- X
- Eu Rohs Directive
- Pro-active compliance (Product out of EU RoHS legal scope)
- Reach Free Of Svhc
- Yes
- Reach Regulation
- Free of Substances of Very High Concern above the threshold
Specifications
- Product Or Component Type
- BOS internal bus extension kit
- Range Of Product
- Modicon STB distributed I/O solution
