Schneider Electric REXL2TMP7
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
This Harmony REXL timing relay can be set between 0.1 seconds and 100 hours, has an output rating of 5A, is 21mm wide and can be supplied with 230V AC. It is a plug-in device, meaning it is quick and easy to install with the need for tools. It also offers a sealable cover, simple and precise settings with rotary trimmers. It is designed for socket plug in, this allows quick and easy installation and minimizes set up and repair time. Status display with 2 LEDs, visually inspect the status of you system without specialized tools. 0 0 0 0 0 0 0 0 0 0 0 0 0 0single function relay, Harmony Timer Relays, 5A, 2CO, 0.1s..100h, on delay, 230V AC
Schneider Electric REXL2TMP7 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Complementary
- Contacts Material
- cadmium free
- Creepage Distance
- 4 kV/3 IEC 60664-1
- Electrical Durability
- 100000 cycles 250 V AC resistive
- Line Rated Current
- 5 A AC
- Local Signalling
- for output in operation 1 LED (red) || for power ON 1 LED (yellow)
- Maximum Switching Capacity
- 4 x 5 A
- Mechanical Durability
- 10000000 cycles
- Minimum Switching Current
- 100 mA
- Net Weight
- 0.05 kg
- Output Overvoltage Protection
- 2 J
- Power Consumption In Va
- 3 VA
- Repeat Accuracy
- +/- 0.5 %
- Reset Time
- 250 ms after time delay, on de-energisation || 50 ms during time delay, on de-energisation
- Setting Accuracy Of Time Delay
- 10 % at full scale 25 °C IEC 61812-1
- Surge Withstand
- 2 kV IEC 61000-4-5 level 3
- Temperature Drift
- 0.05 %/°C
- Temporary Permissible Current
- 10 A < 10 s
- [Ui] Rated Insulation Voltage
- 250 V IEC 255 Group C || 250 V VDE 0010
- [Us] Rated Supply Voltage
- 230 V AC 50/60 Hz
- Voltage Drift
- +/- 0.2 %/V
- Voltage Range
- 0.85...1.15 Us
Contractual warranty
- Warranty
- 18 months
Environment
- Ambient Air Temperature For Operation
- -20-60 °C
- Ambient Air Temperature For Storage
- -40-70 °C
- Dielectric Strength
- 2 kV 1 mA/1 minute 50 Hz IEC 60601-1 || 2 kV 1 mA/1 minute 50 Hz IEC 61812-1
- Disturbance Radiated/Conducted
- class B EN 55022 (EN 55011 group 1)
- Immunity To Microbreaks
- 5 ms
- Immunity To Radioelectric Fields
- 10 V 0.15...80 MHz)IEC 61000-4-6 level 3
- Immunity To Voltage Dips
- >= 95 % / 1 s IEC 61000-4-11 || 30 % / 10 ms IEC 61000-4-11 || 60 % / 100 ms IEC 61000-4-11
- Ip Degree Of Protection
- IP50 conforming to IEC 60529
- Product Certifications
- UL || cUL
- Relative Humidity
- 95-95 % without condensation IEC 60068-2-6
- Resistance To Electromagnetic Fields
- 10 V/m IEC 61000-4-3 level 3
- Resistance To Electrostatic Discharge
- 6 kV in contact IEC 61000-4-2 level 3 || 8 kV in air IEC 61000-4-2 level 3
- Resistance To Fast Transients
- 2 kV IEC 61000-4-4 level 3
- Standards
- IEC 60601-1 || 89/336/EEC || IEC 61000-6-2 || EN 50081-2 || IEC 61812-1 || 73/23/EEC || IEC 60601-2 || 93/68/EEC
- Vibration Resistance
- 0.35 mm 10-55 Hz)IEC 60068-2-6
Offer Sustainability
- California Proposition 65
- WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- China Rohs Regulation
- X
- Environmental Disclosure
- ENVPEP1310019EN
- Eu Rohs Directive
- Pro-active compliance (Product out of EU RoHS legal scope)
- Mercury Free
- Yes
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
- Rohs Exemption Information
- Yes
- Sustainable Offer Status
- Green Premium product
- Weee
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Specifications
- Component Name
- REXL
- Contacts Type And Composition
- 2 C/O
- Discrete Output Type
- relay
- Fixing Mode
- plug-in socket)
- Product Or Component Type
- single function relay
- Range Of Product
- Harmony Timer Relays
- Time Delay Range
- 10...100 h || 1...10 min || 1...10 h || 0.1...1 s || 6...60 min || 6...60 s || 1...10 s
- Time Delay Type
- power on-delay
