Schneider Electric R9F14116
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Resi9 auth. off 1P 16A C 4,5 kA
Schneider Electric R9F14116 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Complementary
- 9 mm Pitch
- 2
- Colour
- White
- Compatibility of the Distribution Block with Comb Tires
- Lower: doubly connected
- Control Method
- Toggle switch
- Depth
- 75 mm
- Description of Blocking Parameters
- Lock to lock in OFF position.
- Earth Fault Protection
- Without
- Electrical Durability
- 4000 cycles AC 50/60 Hz in accordance with EN / IEC 60898-1
- Electromagnetic Release Limit
- 5 ... 10 x In
- Height
- 85 mm
- Joining
- Tunnel type terminals, upper or lower rigid wire (s) || Tunnel type terminals, upper or lower flexible wire (s) || Tunnel type terminals, upper or lower flexible with ferrule
- Local Indication
- ON / OFF indication
- Mains Frequency
- 50/60 Hz
- Mechanical Wear Resistance
- 10,000 cycles
- Mounting Support
- DIN rail
- Restriction Class
- 3 in accordance with EN / IEC 60898-1
- Switch Execution
- Snap fit
- Torque
- 2 Nm (upper or lower)
- [Ue] Rated Operating Voltage
- 230 V AC 50/60 Hz
- [Ui] Rated Isolation Voltage
- 440 V AC 50/60 Hz
- Width
- 18 mm
- Wire Stripping Length
- 14 mm (upper or lower)
Environment
- IP Degree of Protection
- IP40 for modular cabinet in accordance with IEC 60529 || IP20 in accordance with IEC 60529
- Operating Ambient Temperature
- -25 ... 60 ° C
- Pollution Degree
- 2 in accordance with EN / IEC 60898-1
- Storage Ambient Temperature
- -40 ... 80 ° C
Main
- Application Area
- Distribution
- Breaking Capacity
- Icn 4500 A in 230 V AC 50/60 Hz in accordance with EN / IEC 60898-1
- Certification
- VDE || EAC
- Control and Control Unit Technology
- Thermomagnetic
- Curve Code
- C
- [In] Rated Current
- 16 A at 30 ° C
- Network Type
- Alternating current
- Number of Protected Poles
- One
- Pole Description
- 1P
- Product Name
- Resi9 MCB
- Range
- Resi9
- Standards
- EN / IEC 60898-1
- Type of Device or its Accessories
- Miniature circuit breaker
Offer Sustainability
- Compliance with Environmental Status
- Green Premium product category
