Description
Linergy TR is terminal block for Linergy. It belongs to linergy earth terminal block with 4 mm² nominal cross section. It has grey surface treatment. Mounting by clip-on and top connection by single-level 1x1 screw terminals. It could be connection and disconnection by flat screwdriver. It is compatible with spacial enclosures for Prisma G, Prisma P, Pragma, Prisma PH, Prisma Pack, Spacial, Kaedra, TeSys. Sold in lots of 50 units. Ambient air temperature for operation is from -40 to 130 °C conforming to IEC 60216-1 and VDE 0304-T21. Multi standards certified (ATEX, CSA, cURus, DNV, GL, LR, VDE, IEC-Ex, EAC). It is compliant with Green Premium (RoHS/REACH).Terminal block, Linergy TR, spring type, protective earth, 2 points, 4mm², green-yellow, set of 50
Schneider Electric NSYTRR42PE is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Complementary
- Cable Cross Section
- 0.08-4 mm², solid || 0.2-4 mm², flexible with cable end || 0.08-4 mm², flexible without cable end
- Connection Position
- top
- Connections - Terminals
- 1 x spring terminal upstream || 1 x spring terminal downstream
- Creep Resistance
- 500 CTI (> 400 kB) IEC 60093 || 500 CTI (> 400 kB) VDE 0303-T30
- Dielectric Constant
- 3.7 at 1 MHz
- Dielectric Loss
- 0.01 at 1 MHz IEC 60250 || 0.01 at 1 MHz VDE 0303-T4
- Flame Retardance
- V0 0.8 mm UL 94
- Height
- 36.5 mm
- Material
- polyamide 6/6 insulating case
- Net Weight
- 12.7 g
- Number Of Measurement Input
- 2
- Number Of Terminals
- 2
- Product Compatibility
- Spacial enclosures
- Range Compatibility
- Prisma G || Prisma P || Prisma PH || Prisma Pack || Spacial || Kaedra || Pragma || TeSys
- Resistivity
- 10000 MΩ.m IEC 60093 || 10000 MΩ.m VDE 0303-T30
- Surface Resistance
- 1000 GΩ IEC 60093 || 1000 GΩ VDE 0303-T30
- Tool Type
- connection flat screwdriver || disconnection flat screwdriver
- Width
- 6.2 mm
- Wire Stripping Length
- 10 mm
Contractual warranty
- Warranty
- 18 months
Environment
- Ambient Air Temperature For Operation
- -40-130 °C IEC 60216-1 || -40-130 °C VDE 0304-T21
- Dielectric Strength
- 1000 V IEC 60243-1
- Product Certifications
- cURus || LR || GL || IEC-Ex || DNV || EAC || CSA || ATEX || VDE
Offer Sustainability
- China Rohs Regulation
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- Circularity Profile
- null
- Environmental Disclosure
- ENVPEP1304018EN
- Eu Rohs Directive
- Pro-active compliance (Product out of EU RoHS legal scope)
- Halogen Content Performance
- Halogen free plastic parts product
- Mercury Free
- Yes
- Reach Free Of Svhc
- Yes
- Reach Regulation
- Free of Substances of Very High Concern above the threshold
- Rohs Exemption Information
- Yes
- Sustainable Offer Status
- Green Premium product
- Toxic Heavy Metal Free
- Yes
Specifications
- Color
- green-yellow
- Device Short Name
- TRR
- Length
- 56 mm
- Mounting Mode
- clip-on
- Nominal Cross Section
- 4 mm²
- Product Name
- Linergy TR
- Product Or Component Type
- terminal block
- Quantity Per Set
- set of 50
- Range
- Linergy
- Terminal Block Level
- 1
- Terminal Block Type
- protective earth
