Description
Floor standing polyester enclosure, Thalassa PLA, plain door, ventilated canopy, 1250x1250x320mm, IP44, IK10
Schneider Electric NSYPLAT12123G is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Complementary
- Accessibility For Operation
- top || rear || front
- Body Type
- open top and sealed bottom part assembled with side parts
- Color
- Gray RAL 7035)
- Door Opening Side
- right and left 120 °)
- Door Type
- Solid front
- Electrical Insulation Class
- class II
- Lock Type
- 4 points lock, handle with 5 mm double bar insert
- Material
- polyester reinforced with fibreglass
- Number Of Doors
- 2
- Product Certifications
- Veritas
- Removable Parts
- door by hinges || rear panel by fixing element || canopy by fixing element
- Standards
- IEC 62208
Environment
- Ambient Air Temperature For Storage
- -35-90 °C
- Fire Resistance
- 960 °C IEC 62208
- Ik Degree Of Protection
- IK10 IEC 62262 plain door)
- Ip Degree Of Protection
- IP44 IEC 60529 with ventilated canopy)
Offer Sustainability
- China Rohs Regulation
- Product out of China RoHS scope. Substance declaration for your information.
- Circularity Profile
- null
- Environmental Disclosure
- ENVPEP110505EN
- Eu Rohs Directive
- Pro-active compliance (Product out of EU RoHS legal scope)
- Mercury Free
- Yes
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
- Rohs Exemption Information
- Yes
- Sustainable Offer Status
- Green Premium product
Specifications
- Device Application
- multi-purpose
- Device Composition
- 1 top part || 1 bottom part || 2 side part || 2 door || 2 rear panel || 1 canopy
- Device Short Name
- PLAT
- Enclosure Mounting
- floor-standing
- Enclosure Nominal Depth
- 320 mm
- Enclosure Nominal Height
- 1250 mm
- Enclosure Nominal Width
- 1250 mm
- Product Name
- Thalassa PLA
- Product Or Component Type
- suitable enclosure
- Range
- Thalassa
