Schneider Electric NSYEBCD12614
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
NSYEB power distribution blocks are enclosed IEC versions of our NEMA 9080 power distribution blocks, which are finger safe. The terminals of these power terminal blocks are finger safe from the front according to IP20. They are one pole modular units with an interlocking dovetail feature that enables ganging of the blocks to create multipole configurations according to application requirements. This block has a Short-Circuit Current Ratings (SCCR) of up to 100 kA with fuses and circuit breakers. Refer to the catalog for details on this. The lugs in these blocks are available with either copper or aluminum. This block has a tin plated copper lug. The line side lug of this block is rated to 200A at 600 V when copper wire is used. The line side terminal will accept 14 AWG to 3/0 AWG copper wires. The four load side terminals will accept 14 AWG to 2 AWG copper wires. This block can be mounted on 35 mm DIN rail. This block is 3.61 inches tall, 1.21 inches wide and 2.71 inches deep. This block is UL Listed, CSA cerified and RoHS compliant.Power distribution block, Linergy, enclosed, 200A CU, 600 V, 1 line side lug, 4 load side lug, CU lug, rail mount
Schneider Electric NSYEBCD12614 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Complementary
- Colour Of Enclosure
- grey
- Connections - Terminals
- line lug 180 lbf.in AWG 8...AWG 3/0 copper || line lug 50 lbf.in AWG 14...AWG 10 copper || load lug 50 lbf.in AWG 8...AWG 2 copper || load lug 40 lbf.in AWG 14...AWG 10 copper
- Depth
- 2.71 in
- Electrical Connection
- tin plated copper lugs
- Height
- 3.61 in
- Line Rated Current
- 200-200 A copper
- Material
- thermoplastic block
- Mounting Support
- 35 mm DIN rail
- Number Of Cables
- line 1 , AWG 14...AWG 3/0, copper || load 4 , AWG 14...AWG 2, copper
- Number Of Terminals
- 1 line || 4 load
- Short-Circuit Current
- 100 kA
- Tightening Torque
- line 180 lb.in, AWG 8...AWG 3/0, copper || line 50 lb.in, AWG 14...AWG 10, copper || load 50 lb.in, AWG 8...AWG 2, copper || load 40 lb.in, AWG 14...AWG 10, copper
- [Ue] Rated Operational Voltage
- 600 V AC/DC
- Width
- 1.21 in
- Wire Stripping Length
- load: 0.69 in for bottom connection || line: 0.88 in || load: 0.69 in for top connection
Environment
- Ambient Air Temperature For Operation
- -40-257 °F
- Dielectric Strength
- 1000 V 70 mm² IEC 60947-7-1
- Product Certifications
- CE || UL listed file E323110 CCN QPQS || CSA file 70361 class 6228 01
Offer Sustainability
- China Rohs Regulation
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- Eu Rohs Directive
- Compliant
- Halogen Content Performance
- Halogen free product
- Mercury Free
- Yes
- Reach Free Of Svhc
- Yes
- Reach Regulation
- Free of Substances of Very High Concern above the threshold
- Rohs Exemption Information
- Yes
- Toxic Heavy Metal Free
- Yes
- Weee
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Specifications
- Product Or Component Type
- Power Distribution Block
- Range Of Product
- NSYEB
