Schneider Electric MPZB10S40F
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Square D™ brand Mini Power-Zone™ unit substation from Schneider Electric provides the answer to requirements for a portable, compact power supply for small loads. The Mini Power-Zone unit substation uses a separate transformer and panel section. This allows the panel section to be removed and wired first if desired. These transformers can be replaced without disturbing the panel section and associated wiring. The new transformer simply slides into the top of the panel section and primary and secondary leads are reconnected to the main circuit breakers. The panel section uses Square D™ brand QO™ style circuit breakers. Use Qwik-Gard™ circuit breakers for required ground fault protection. This Mini Power-Zone Sealed Transformer is a 1 phase, with a primary voltage of 480V and a secondary voltage of 120/240V with 2 tap offs @5 % FCBN taps. This transformer has a box number AA and a insulation temperature rating of 185 °C. These transformers are installed on the interior of the load center that has 16 spaces. With a rated power of 10kVA, it has a short circuit current of 18kA. This transformer has a temperature rise of 115°C and is epoxy-resin encapsulated. The enclosure material is hot-rolled steel and is rated at NEMA 3R. This transformer complies to UL listed standards. This product comes with an 18 month warranrty.Unit substation, Mini Power-Zone, bolt on, 10kVA, 1 phase, 480V primary, 120/240V secondary, 18kA, AA
Schneider Electric MPZB10S40F is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Contractual warranty
- Warranty
- 18 months
Offer Sustainability
- California Proposition 65
- WARNING: This product can expose you to chemicals including: Nickel (Metallic), which is known to the State of California to cause cancer, and Bisphenol A (BPA), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- China Rohs Regulation
- Product out of China RoHS scope. Substance declaration for your information.
- Eu Rohs Directive
- Compliant
- Mercury Free
- Yes
- Pvc Free
- Yes
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
- Rohs Exemption Information
- Yes
Specifications
- Board Name
- NQ Panelboard interior
- Box Number
- AA
- Circuit Breaker Application
- FAL24030 primary main breaker 30 A || QO260 secondary main breaker 60 A || QO feeder breaker 40 A
- Insulation Temperature
- 185 °C
- Material
- copper
- Nema Degree Of Protection
- NEMA 3R hot-rolled steel
- Number Of Circuits
- 16
- Number Of Spaces
- 16
- Number Of Tap-Offs
- 2 5 % FCBN
- Phase
- 1 phase
- Primary Voltage
- 480 V
- Product Certifications
- UL Listed
- Product Or Component Type
- Sealed Transformer
- Range Of Product
- Mini Power-Zone
- Rated Power In Va
- 10 kVA
- Secondary Voltage
- 120/240 V
- Short-Circuit Current
- 18 kA
- Temperature Rise
- 115 °C
