Description
LA1KN02 is a Schneider Electric instantaneous auxiliary contact block for TeSys K contactors. It provides 2NC contacts rated up to 10A 690V AC, connection by screw clamp terminals. Easy clip-on mounting on front, it procures high reliability and durability. Available worldwide, it is multi-standards certified (IEC, UL, CSA, CCC) and Green Premium compliant (RoHs/Reach). Multi standards certified (IEC, UL, CSA, CCC), Green Premium compliant (RoHS/REACh).Auxiliary contact block, TeSys K, 2NC, front mounting, screw clamp terminals
Schneider Electric LA1KN02 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Complementary
- Associated Fuse Rating
- 10 A gG <= 690 V IEC 60947
- Connections - Terminals
- screw clamp terminals 1 0.34-1.5 mm²flexible with cable end || screw clamp terminals 1 0.75-4 mm²flexible without cable end || screw clamp terminals 1 1.5-4 mm²rigid || screw clamp terminals 2 0.34-1.5 mm²flexible with cable end || screw clamp terminals 2 0.75-4 mm²flexible without cable end || screw clamp terminals 2 1.5-4 mm²rigid
- Depth
- 35 mm
- Height
- 30 mm
- Insulation Resistance
- > 10 MOhm
- Irms Rated Making Capacity
- 110 A <= 690 V AC IEC 60947
- Minimum Switching Current
- 5 mA
- Minimum Switching Voltage
- 17 V
- Net Weight
- 0.045 kg
- Non Overlap Distance
- 0.5 mm
- Permissible Short-Time Rating
- 80 A 1 s || 60 A 500 ms || 110 A 100 ms
- Tightening Torque
- 1.3 N.m Philips No 2 || 1.3 N.m pozidriv No 2
- Width
- 38 mm
Contractual warranty
- Warranty
- 18 months
Environment
- Ambient Air Temperature For Operation
- -25-50 °C
- Ambient Air Temperature For Storage
- -50-80 °C
- Environmental Characteristic
- normal environment
- Ip Degree Of Protection
- IP20 conforming to IEC 60529
- Operating Altitude
- 6561.68 ft (2000 m)
- Protective Treatment
- TC IEC 60068
Offer Sustainability
- China Rohs Regulation
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- Circularity Profile
- null
- Environmental Disclosure
- ENVPEP2106022
- Eu Rohs Directive
- Compliant
- Mercury Free
- Yes
- Reach Free Of Svhc
- Yes
- Reach Regulation
- Free of Substances of Very High Concern above the threshold
- Rohs Exemption Information
- Yes
- Sustainable Offer Status
- Green Premium product
- Toxic Heavy Metal Free
- Yes
- Weee
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Specifications
- Auxiliary Contacts Operation
- instantaneous
- Device Short Name
- LA1
- [Ith] Conventional Free Air Thermal Current
- 10 A 50 °C
- Mounting Location
- front
- Pole Contact Composition
- 2 NC
- Product Certifications
- CB Scheme || CCC || UL || CSA || CE || UKCA
- Product Name
- TeSys K
- Product Or Component Type
- auxiliary contact block
- Range
- TeSys
- Range Compatibility
- TeSys K LC1K || TeSys K CA2K || TeSys K CA3K || TeSys K CA4K
- Standards
- EN/IEC 60947-5-1 || UL 60947-5-1 || CSA C22.2 No 60947-5-1 || GB/T 14048.5 || JIS C8201-5-1
- [Ue] Rated Operational Voltage
- 690 V AC 25...400 Hz
- [Ui] Rated Insulation Voltage
- 690 V IEC 60947-5-1 || 600 V UL 60947-5-1 || 600 V CSA C22.2 No 60947-5-1
