Schneider Electric LA1DZ40
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
TeSys Deca instantaneous auxiliary contact block with dust and damp protected contacts, for LC1D contactors and CAD control relays in harsh industral environments. It provides 2NO protected contacts rated up to 0.1A 125V AC / 30V DC, 2NO not protected contacts rated up to 10A 690V AC, connection by screw clamp terminals. Protected contacts with very low minimum switching capacity (5V / 1mA) thanks to gold alloy contact material. Front mounting by clip-on, it procures high reliability and durability. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh).Auxiliary contact block, TeSys Deca, 2NO(sealed)+2NO, front mounting, screw clamp terminals
Schneider Electric LA1DZ40 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Complementary
- Connections - Terminals
- screw clamp terminals 1 1-2.5 mm²flexible with cable end || screw clamp terminals 1 1-2.5 mm²flexible without cable end || screw clamp terminals 2 1-2.5 mm²flexible with cable end || screw clamp terminals 2 1-2.5 mm²flexible without cable end || screw clamp terminals 1 1-2.5 mm²rigid || screw clamp terminals 2 1-2.5 mm²rigid
- Depth
- 39 mm
- Height
- 48 mm
- Insulation Resistance
- > 10 MOhm
- Mechanical Durability
- 5 Mcycles
- Minimum Switching Current
- 1 mA protected contact || 5 mA non-protected contact
- Minimum Switching Voltage
- 5 V protected contact || 17 V non-protected contact
- Net Weight
- 0.05 kg
- Protection Type
- gG fuse 10 A non-protected contact
- Tightening Torque
- 1.7 N.m flat Ø 6 mm || 1.7 N.m Philips No 2 || 1.7 N.m pozidriv No 2
- Width
- 44 mm
Contractual warranty
- Warranty
- 18 months
Environment
- Ambient Air Temperature For Operation
- -25-70 °C
- Ambient Air Temperature For Storage
- -25-70 °C
- Environmental Characteristic
- harsh environment
- Ip Degree Of Protection
- IP2X conforming to IEC 60529
- Protective Treatment
- TH IEC 60068
Offer Sustainability
- China Rohs Regulation
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- Circularity Profile
- null
- Environmental Disclosure
- ENVPEP110807EN_V2
- Eu Rohs Directive
- Compliant
- Mercury Free
- Yes
- Reach Free Of Svhc
- Yes
- Reach Regulation
- Free of Substances of Very High Concern above the threshold
- Rohs Exemption Information
- Yes
- Sustainable Offer Status
- Green Premium product
- Toxic Heavy Metal Free
- Yes
- Weee
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Specifications
- Auxiliary Contacts Operation
- instantaneous
- Device Short Name
- LA1
- [Ie] Rated Operational Current
- 0.1 A protected contact
- [Ith] Conventional Free Air Thermal Current
- 10 A 40 °C non-protected contact
- Mounting Location
- front
- Pole Contact Composition
- 2 NO (sealed) + 2 NO
- Product Certifications
- CB || UL || CSA || CCC || EAC || UKCA
- Product Name
- TeSys Deca
- Product Or Component Type
- auxiliary contact block
- Range
- TeSys
- Range Compatibility
- TeSys D CAD || TeSys D LC1D || TeSys F LC1F || TeSys F CR1F || TeSys Deca CAD || TeSys Deca LC1D
- Standards
- EN/IEC 60947-5-1 || UL 60947-5-1 || CSA C22.2 No 60947-5-1 || GB/T 14048.5
- [Ue] Rated Operational Voltage
- 125 V AC protected contact || 30 V DC protected contact || 690 V AC non-protected contact
- [Ui] Rated Insulation Voltage
- 250 V - protected contact IEC 60947-5-1 || 690 V - non-protected contact IEC 60947-5-1 || 600 V - non-protected contact UL 60947-5-1 || 600 V - non-protected contact CSA C22.2 No 60947-5-1
