Schneider Electric HMIGTO4310FW
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Advanced touchscreen panel, Harmony GTO, 7.5 Color Touch VGA TFT, logo removed
Schneider Electric HMIGTO4310FW is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Complementary
- Backlight Lifespan
- 50000 hours white 25 °C
- Brightness
- 16 levels by touch panel || 16 levels by software
- Character Font
- Taiwanese (traditional Chinese) || Japanese (ANK, Kanji) || Chinese (simplified Chinese) || ASCII || Korean
- Data Backed Up
- 512 KB internal RAM SRAM)
- Data Storage Equipment
- SD card, <= 32 GB || SDHC card, <= 32 GB
- Depth
- 60 mm
- Display Resolution
- 640 x 480 pixels VGA
- Display Type
- backlit colour TFT LCD
- Downloadable Protocols
- Schneider Electric Modicon Modbus || Schneider Electric Modicon Uni-TE || Schneider Electric Modicon Modbus Plus || Schneider Electric Modicon FIPWAY || Mitsubishi Melsec third party protocols || Omron Sysmac third party protocols || Rockwell Automation Allen-Bradley third party protocols || Siemens Simatic third party protocols || Schneider Electric Modicon Modbus TCP
- Enclosure Material
- PPT
- Fixing Mode
- by 4 screw clamps
- Front Material
- PPT
- Height
- 173 mm
- Inrush Current
- 30 A
- Integrated Connection Type
- COM1 serial link SUB-D 9 RS232C 2400...115200 bps || COM2 serial link RJ45 RS485 2400...115200 bps || COM2 serial link RJ45 RS485 187.5 kbps Siemens MPI || Ethernet RJ45 10BASE-T/100BASE-TX || Ethernet RJ45 IEEE 802.3 || USB 2.0 type A || USB 2.0 type mini B
- Local Signalling
- status LED green, steady offline || status LED green, steady operating || status LED orange, flashing software starting up || status LED red, steady power supply (ON) || status LED clear, faded power supply (OFF) || COM2 LED yellow, steady data is being transmitted || COM2 LED yellow, faded no data transmission || SD card LED green, steady card is inserted || SD card LED green, faded card is not inserted or is not being accessed
- Maximum Power Consumption In W
- 8 W when power is not supplied to external devices || 5 W when backlight is OFF || 5.5 W when backlight is dimmed || 12 W
- Memory Description
- flash EPROM, 96 MB
- Net Weight
- 1.2 kg
- Product Mounting
- flush mounting
- Software Designation
- Vijeo Designer configuration software >= V6.1
- Supply Voltage Limits
- 19.2-28.8 V
- Terminal Type
- touchscreen display
- Touch Panel
- resistive film, 1000000 cycles
- Touch Sensitive Zone
- 1024 x 1024
- Type Of Cooling
- natural convection
- [Us] Rated Supply Voltage
- 24 V DC
- Width
- 218 mm
Environment
- Ambient Air Temperature For Operation
- 0-55 °C
- Ambient Air Temperature For Storage
- -20-60 °C
- Ip Degree Of Protection
- IP20 IEC 60529 rear panel) || IP65 IEC 60529 front panel)
- Nema Degree Of Protection
- NEMA 4X front panel (indoor use)
- Operating Altitude
- < 6561.68 ft (2000 m)
- Product Certifications
- KCC || CE || C-tick || cULus || UKCA || UKEX
- Relative Humidity
- 10-90 % without condensation
- Resistance To Electrostatic Discharge
- 6 kV contact discharge IEC 61000-4-2 level 3
- Shock Resistance
- 147 m/s² 3 chocks in each direction X, Y and Z EN/IEC 61131-2
- Standards
- IEC 61000-6-2 || UL 508 || EN 61131-2
- Vibration Resistance
- 3.5 mm 5-9 Hz) - X, Y, Z directions for 10 cycles (approx. 100 min) - EN/IEC 61131-2 || 1 gn 9-150 Hz) - X, Y, Z directions for 10 cycles (approx. 100 min) - EN/IEC 61131-2
Offer Sustainability
- California Proposition 65
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- China Rohs Regulation
- X
- Circularity Profile
- ENVEOLI1402012EN
- Environmental Disclosure
- ENVPEP1402012EN
- Eu Rohs Directive
- Pro-active compliance (Product out of EU RoHS legal scope)
- Mercury Free
- Yes
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
- Rohs Exemption Information
- Yes
- Sustainable Offer Status
- Green Premium product
- Weee
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Specifications
- Battery Type
- lithium internal RAM 100 days 5 day(s) 10 year(s)
- Display Colour
- 65536 colours
- Display Size
- 7.5 inch
- Product Or Component Type
- advanced touchscreen panel
- Range Of Product
- Harmony GTO
- Supply
- external source
