Schneider Electric GV4PE07S6
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
TeSys GV motor circuit breaker, 3 poles (3P), 7A/690V, for protection of 3-phase motors 1.5-3kW@400V. It provides thermal magnetic protection and additional motor protection functions, breaking capacity Icu 100kA@400V, start-stop control by toggle, connection for bars or cables with lugs. Thermal protection adjustable by dials with a setting current Ir in range 2.9-7A and a selectable tripping class 10 or 20, magnetic protection at 17 In. Additional protections have fixed pick-up and include short time delay protection Isd at 13 Ir, phase unbalance and loss protection, ground fault protection. It makes internal locations available for additional auxiliary contact blocks (OF, SD), and voltage trip units (MN, MX). Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine, ATEX), Green Premium compliant (RoHS/REACh).Motor circuit breaker, TeSys GV4, 3P, 7A, Icu 100kA, thermal magnetic, lugs terminals
Schneider Electric GV4PE07S6 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Complementary
- Breaking Capacity
- 120 kA Icu 220...240 V AC 50/60 Hz IEC 60947-2 || 100 kA Icu 380...415 V AC 50/60 Hz IEC 60947-2 || 70 kA Icu 440 V AC 50/60 Hz IEC 60947-2 || 30 kA Icu 500 V AC 50/60 Hz IEC 60947-2 || 18 kA Icu 525 V AC 50/60 Hz IEC 60947-2 || 100 kA 208Y/120 V AC 50/60 Hz UL 60947 || 100 kA 240 V AC 50/60 Hz UL 60947 || 65 kA 480Y/277 V AC 50/60 Hz UL 60947 || 10 kA Icu 660...690 V AC 50/60 Hz IEC 60947-2 || 25 kA 600Y/347 V AC 50/60 Hz UL 60947
- Color
- Gray RAL 7016)
- Connection Pitch
- 27 mm without spreaders || 35 mm with spreaders
- Connections - Terminals
- lugs-ring terminals
- Control Type
- toggle
- Depth
- 116 mm
- Electrical Durability
- 40000 cycles AC-3 440 V In/2 || 40000 cycles AC-3 440 V In
- Height
- 155 mm
- [Ith] Conventional Free Air Thermal Current
- 115 A IEC 60947-4-1
- Line Rated Current
- 7 A
- Magnetic Tripping Current
- 119-119 A
- Maximum Operating Rate
- 25 cyc/h
- Mechanical Durability
- 40000 cycles
- Mechanical Robustness
- vibrations +/- 1 mm 2...13.2 Hz IEC 60068-2-6 || vibrations 0.7 gn 13.2...100 Hz IEC 60068-2-6 || shocks 15 gn 11 ms IEC 60068-2-27
- Motor Power Kw
- 1.5-1.5 kW 400...415 V AC 50/60 Hz || 2.2-2.2 kW 400...415 V AC 50/60 Hz || 2.5-2.5 kW 400...415 V AC 50/60 Hz || 3-3 kW 400...415 V AC 50/60 Hz || 2.2-2.2 kW 500 V AC 50/60 Hz || 2.5-2.5 kW 500 V AC 50/60 Hz || 3-3 kW 500 V AC 50/60 Hz || 4-4 kW 500 V AC 50/60 Hz || 3-3 kW 660...690 V AC 50/60 Hz || 4-4 kW 660...690 V AC 50/60 Hz || 5.5-5.5 kW 660...690 V AC 50/60 Hz || 7.5-7.5 kW 660...690 V AC 50/60 Hz
- Net Weight
- 1.45 kg
- Operating Position
- any position
- Phase Failure Sensitivity
- yes IEC 60947-4-1
- Poles Description
- 3P
- Power Dissipation Per Pole
- 4.6 W
- Rated Duty
- continuous IEC 60947-4-1
- Suitability For Isolation
- yes IEC 60947-1
- Tightening Torque
- 9 N.m 16-95 mm² || 5 N.m 1.5-10 mm²
- [Ue] Rated Operational Voltage
- 690 V AC 50/60 Hz IEC 60947-2
- [Uimp] Rated Impulse Withstand Voltage
- 8 kV IEC 60947-2
- [Ui] Rated Insulation Voltage
- 800 V AC 50/60 Hz IEC 60947-2
- Utilisation Category
- category A IEC 60947-2 || AC-3 IEC 60947-4-1
- Width
- 81 mm
Contractual warranty
- Warranty
- 18 months
Environment
- Ambient Air Temperature For Operation
- -25-70 °C
- Ambient Air Temperature For Storage
- -50-85 °C
- Climatic Withstand
- IACS E10
- Fire Resistance
- 960 °C IEC 60695-2-11
- Ik Degree Of Protection
- IK07 IEC 62262
- Ip Degree Of Protection
- IP40 IEC 60529
- Operating Altitude
- 5000 m
- Pollution Degree
- 3
- Product Certifications
- IEC || UL || CSA || CCC || EAC || ATEX || EU-RO MR
- Standards
- CSA C22.2 No 60947-4-1 || UL 60947-4-1 || EN/IEC 60947-4-1 || EN/IEC 60947-2
Offer Sustainability
- China Rohs Regulation
- Product out of China RoHS scope. Substance declaration for your information.
- Circularity Profile
- ENVEOLI1704004EN
- Environmental Disclosure
- ENVPEP1704004EN
- Eu Rohs Directive
- Compliant
- Halogen Content Performance
- Halogen free plastic parts product
- Mercury Free
- Yes
- Pvc Free
- Yes
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
- Rohs Exemption Information
- Yes
- Sustainable Offer Status
- Green Premium product
- Weee
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Specifications
- Device Application
- motor protection
- Device Short Name
- GV4PE
- Product Name
- TeSys GV4 || TeSys Deca
- Product Or Component Type
- motor circuit breaker
- Range
- TeSys Deca
- Range Of Product
- TeSys GV4
- Trip Unit Technology
- electronic || thermal-magnetic
