Schneider Electric GV4AS137
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
TeSys GV electrical trip unit, MX shunt trip, 110-130V AC 50Hz/60Hz or 125V DC, for motor circuit breakers GV4. It trips the circuit breaker when the control voltage is applied in limits 0.7-1.1 Uc with an impulse duration greater than 20ms or a maintained signal. To be plugged inside the circuit breaker, connection by spring terminals. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh).Voltage release, TeSys GV4, MX coil, 110 to 130VAC 50/60Hz, 125VDC
Schneider Electric GV4AS137 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Complementary
- Connections - Terminals
- spring terminals 1 0.5-1.5 mm² flexible without cable end
- Impulse Duration
- >= 20 ms
- Maximum Hold-In Power Consumption In Va
- 10 VA
- Maximum Hold-In Power Consumption In W
- 1 W
- Maximum Inrush Power In Va
- 6 VA
- Maximum Inrush Power In W
- 4 W
- Mechanical Durability
- 20000 cycles
- Mounting Mode
- internal mounting
- Operating Time
- < 50 ms
- Threshold Tripping Voltage
- 0.7...1.1 Un failsafe opening || < 0.7 Un possible opening
- [Ui] Rated Insulation Voltage
- 130 V IEC 60947-1
- Wire Stripping Length
- 8 mm
Environment
- Quantity Per Set
- set of 1
Offer Sustainability
- California Proposition 65
- WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- China Rohs Regulation
- Product out of China RoHS scope. Substance declaration for your information.
- Eu Rohs Directive
- Compliant
- Mercury Free
- Yes
- Rohs Exemption Information
- Yes
- Weee
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Specifications
- Device Application
- control
- Device Short Name
- MX
- Product Or Component Type
- voltage release
- Range
- TeSys
- Range Compatibility
- TeSys (TeSys GV4) || TeSys (TeSys BV4)
- [Uc] Control Circuit Voltage
- 110...130 V AC 50/60 Hz || 125 V DC
- Voltage Release Type
- shunt trip release
