Schneider Electric CA3KN22JD
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
TeSys K control relay, 4 contacts (2NO + 2NC), 10A/690V, for control of electromagnetic loads AC-15/DC-13. It provides a 12V DC control circuit with no inrush consumption, connection by screw clamp terminals. For high operating rates until 180 cycles/min and ambient temperature -25/+50°C, it procures high reliability and durability. Compact (45mm width), for clipping on 35mm DIN rail or fixing by screw. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium product (RoHS/REACh).Control relay, TeSys K, 2 NO + 2 NC, lt or eq to 690V, 12VDC standard coil
Schneider Electric CA3KN22JD is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Complementary
- Associated Fuse Rating
- 10 A gG IEC 60947 || 10 A gG VDE 0660
- Connections - Terminals
- screw clamp terminals 1 1.5-4 mm²solid || screw clamp terminals 2 1.5-4 mm²solid || screw clamp terminals 1 0.75-4 mm²flexible with cable end || screw clamp terminals 2 0.75-4 mm²flexible without cable end || screw clamp terminals 1 0.34-1.5 mm²flexible with cable end || screw clamp terminals 2 0.34-1.5 mm²flexible without cable end
- Control Circuit Voltage Limits
- operational 0.8...1.15 Uc 50 °C) || drop-out 0.1...0.75 Uc 50 °C)
- Depth
- 57 mm
- Heat Dissipation
- 3-3 W
- Height
- 58 mm
- Hold-In Power Consumption In W
- 3-3 W 20 °C
- Immunity To Microbreaks
- 2 ms
- Inrush Power In W
- 3-3 W 20 °C)
- Insulation Resistance
- > 10 MOhm
- Irms Rated Making Capacity
- 110 A IEC 60947
- [Ith] Conventional Free Air Thermal Current
- 10 A 50 °C
- Maximum Operating Rate
- 10000 cyc/h
- Mechanical Durability
- 20 Mcycles
- Minimum Switching Current
- 5 mA
- Minimum Switching Voltage
- 17 V
- Mounting Support
- rail || plate
- Net Weight
- 0.225 kg
- Non Overlap Distance
- 0.5 mm
- Operating Time
- 10 ms coil de-energisation and NO opening || 30...40 ms coil energisation and NO closing || 15 ms coil de-energisation and NC closing || 25...35 ms coil energisation and NC opening
- Tightening Torque
- 1.3 N.m screw clamp terminals flat Ø 6 mm || 1.3 N.m screw clamp terminals Philips No 2 6 mm || 1.3 N.m screw clamp terminals pozidriv No 2
- [Ui] Rated Insulation Voltage
- 690 V IEC 60947 || 750 V VDE 0110 group C || 690 V BS 5424 || 600 V CSA C22.2 No 14
- Width
- 45 mm
Contractual warranty
- Warranty
- 18 months
Environment
- Ambient Air Temperature For Operation
- -25-50 °C
- Ambient Air Temperature For Storage
- -50-80 °C
- Flame Retardance
- V1 conforming to UL 94 || requirement 2 conforming to NF F 16-101 || requirement 2 conforming to NF F 16-102
- Ip Degree Of Protection
- IP2X
- Mechanical Robustness
- vibrations contactor open2 Gn, 5...300 Hz IEC 60068-2-6 || vibrations contactor closed4 Gn, 5...300 Hz IEC 60068-2-6 || shocks contactor open10 Gn for 11 ms IEC 60068-2-27 || shocks contactor closed15 Gn for 11 ms IEC 60068-2-27
- Operating Altitude
- 6561.68 ft (2000 m) without derating
- Product Certifications
- CB Scheme || CCC || UL || CSA || EAC || CE || UKCA
- Protective Treatment
- TC IEC 60068
- Standards
- EN/IEC 60947-4-1 || GB/T 14048.4 || UL 60947-4-1 || CSA C22.2 No 60947-4-1 || JIS C8201-4-1
Offer Sustainability
- California Proposition 65
- WARNING: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
- China Rohs Regulation
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- Circularity Profile
- ENVEOLI1503003EN
- Environmental Disclosure
- ENVPEP1503003EN
- Eu Rohs Directive
- Compliant
- Mercury Free
- Yes
- Reach Free Of Svhc
- Yes
- Reach Regulation
- Free of Substances of Very High Concern above the threshold
- Rohs Exemption Information
- Yes
- Sustainable Offer Status
- Green Premium product
- Toxic Heavy Metal Free
- Yes
- Weee
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Specifications
- Contactor Application
- control circuit
- Control Circuit Type
- DC standard
- Device Short Name
- CA3K
- Pole Contact Composition
- 2 NO + 2 NC
- Product Name
- TeSys CAK
- Product Or Component Type
- control relay
- Range
- TeSys
- [Uc] Control Circuit Voltage
- 12 V DC
- [Ue] Rated Operational Voltage
- <= 690 V <= 400 Hz
- Utilisation Category
- DC-13 || AC-15
