Schneider Electric BDL36000S12
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Automatic Switch, PowerPacT B, Unit Mount, 600 V AC, 125 A, 3 Pole, EverLink
Schneider Electric BDL36000S12 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Complementary
- 9 Mm Pitches
- 9
- Awg Gauge
- AWG 6...AWG 2/0 fine stranded aluminium/copper || AWG 14...AWG 3/0 rigid or stranded aluminium/copper
- Breaking Capacity Code
- D
- Color
- Gray RAL 7016)
- Connection Pitch
- 27 mm
- Contact Position Indicator
- yes
- Control Type
- toggle
- Depth
- 89 mm
- Electrical Connection
- Everlink lug, line || Everlink lug, load
- Electrical Durability
- 10000 cycles IEC 947-1 Annex K ed 5.2 440 V In
- Height
- 137 mm
- Line Rated Current
- 125 A
- Local Signalling
- for presence of auxiliary contacts flag (green)
- Magnetic Hold Current
- 880 A
- Magnetic Tripping Current
- 1320-1320 A
- Mechanical Durability
- 15000 cycles IEC 947-1 Annex K ed 5.2
- Mounting Mode
- clip-on 35 x 15 mm symmetrical DIN rail) || by screws plate)
- Number Of Slots
- 1 auxiliary switch OF plug-in) || 1 voltage release MN or MX plug-in) || 1 alarm switch SD plug-in)
- Poles Description
- 3P
- Quantity Per Set
- set of 1
- Short-Circuit Withstand
- 25 kA 208Y/120 V UL 489 || 25 kA 240 V UL 489 || 18 kA 480Y/277 V UL 489 || 18 kA 480 V UL 489 || 14 kA 600 V UL 489
- Tightening Torque
- 5-5 N.m 2.5-10 mm² || 9-9 N.m 16-95 mm²
- [Ue] Rated Operational Voltage
- 600Y/347 V AC 50/60 Hz UL 489
- Width
- 81 mm
- Wire Stripping Length
- 20 mm
Environment
- Ambient Air Temperature For Operation
- -25-70 °C
- Ambient Air Temperature For Storage
- -50-85 °C
- Operating Altitude
- 6561.68 ft (2000 m) without derating || 5000 m with derating
- Product Certifications
- UL
- Quality Labels
- CE
- Standards
- UL 489
Offer Sustainability
- California Proposition 65
- WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
- China Rohs Regulation
- Product out of China RoHS scope. Substance declaration for your information.
- Circularity Profile
- null
- Environmental Disclosure
- ENVPEP1610005EN
- Eu Rohs Directive
- Compliant
- Halogen Content Performance
- Halogen free product
- Mercury Free
- Yes
- Pvc Free
- Yes
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
- Rohs Exemption Information
- Yes
- Sustainable Offer Status
- Green Premium product
- Weee
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Specifications
- Device Application
- distribution
- Product Name
- PowerPact B
- Product Or Component Type
- automatic switch
- Range
- PowerPact
