Schneider Electric ABR7S23
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
This product is part of the Modicon ABE7 range, an offer of connection sub-bases for Telefast pre-wired system. This plug-in electromechanical relay is compatible with Modicon ABE7 connection sub-bases. It has 1 change over contact. It is a solid state relay with a control circuit voltage of 24V DC, a conventional free air thermal current of 5A and a maximum power dissipation per pole is 0.36W. It offers electrical durability of 500000 cycles and mechanical durability of 20 million cycles. The width pitch is 10mm. It weighs 0.01kg. It is suitable for all types of industrial applications. This product is suitable for use with Modicon ABE7P16T215, ABE7P16T230, ABE7P16T212, ABE7R16T231, ABE7P16T214, ABE7P16T230E, ABE7R16T230 and ABE7P16T210 sub-base. Modicon ABE7 means greater simplicity to rationalise wiring in your automation system equipment. Pre-wired system enabling connection and adaptation of control signals of PLC cards equipped with HE10 connectors.plug-in electromechanical relay - 10 mm - 24 V DC - 1 CO
Schneider Electric ABR7S23 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Complementary
- Associated Fuse Rating
- 1 A, fast blow
- Contacts Type And Composition
- 1 C/O
- Drop-Out Current
- 1 mA 20 °C
- Drop-Out Voltage
- 2.4 V 20 °C
- Electrical Durability
- 500000 cycles 1200 mA 230 V AC-12 || 500000 cycles 1200 mA 24 V DC-12 || 500000 cycles 450 mA 24 V DC-13 10 ms || 500000 cycles 700 mA 230 V AC-15
- Electrical Reliability
- 1e-008
- [Ith] Conventional Free Air Thermal Current
- 5 A
- Maximum Power Dissipation Per Pole
- 0.36 W
- Maximum Switching Voltage
- 130 V DC IEC 60947-5-1 || 250 V AC 50/60 Hz IEC 60947-5-1
- Mechanical Durability
- 20000000 cycles
- Minimum Switching Current
- 10 mA >= 5 V
- Net Weight
- 0.01 kg || 0.008 kg
- Operating Rate In Hz
- 10 Hz no load || 0.5 Hz at Ie
- Product Compatibility
- ABE7P16T215 || ABE7P16T230 || ABE7P16T212 || ABE7R16T231 || ABE7P16T214 || ABE7P16T230E || ABE7R16T230 || ABE7P16T210
- Threshold Tripping Voltage
- 19.7 V 40 °C
- [Uc] Control Circuit Voltage
- 24 V
- [Uimp] Rated Impulse Withstand Voltage
- 2.5 kV IEC 60947-1
- Width Pitch Dimension
- 10 mm
Contractual warranty
- Warranty
- 18 months
Environment
- Dielectric Strength
- 2000 V IEC 60947-1
- Max Immunity To Microbreaks
- 5 ms
Offer Sustainability
- California Proposition 65
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- China Rohs Regulation
- X
- Eu Rohs Directive
- Pro-active compliance (Product out of EU RoHS legal scope)
- Mercury Free
- Yes
- Pvc Free
- Yes
- Reach Free Of Svhc
- Yes
- Reach Regulation
- Free of Substances of Very High Concern above the threshold
- Rohs Exemption Information
- Yes
- Toxic Heavy Metal Free
- Yes
Specifications
- Control Circuit Type
- DC
- Product Or Component Type
- plug-in electromechanical relay
- Quantity Per Set
- set of 4
- Range Of Product
- Advantys Telefast ABE7
