Description
We offer both product lines with factory installed overcurrent protection fuse blocks. Type TF and EOF transformers consist of two primary fuse blocks and one secondary fuse block, a configuration that meets the majority of overcurrent needs by panel builders and machinery OEMs. Since the fuse blocks are pre-wired and mounted on top of the transformer, the Type TF and EOF transformers have the same footprint as the Type T and Type EO units, respectively. This design frees up space normally used for separate fuse blocks. We also have an extensive fuse block offering for custom applications. See the overcurrent section of this catalog for full details. This Industrial Control Transformer has a power rating of 2000VA and is 1 phase. This transformer has a 220 x 440V primary voltage and 110V secondary voltage. This transformer complies to UL, CE & CSA standards. Dimensions for this product are 7.46 in (H), 7.06 in (W), 7.17 in (D). This transformer has screw clamp terminals connections. The material used for this product is copper used in the winding.This product has a compatability for FSC2. This transformer has screw clamp terminals connections. The material used for this product is copper used in the winding. This product has a compatability for FSC2.Industrial control transformer, Type TF, 1 phase, 2000VA, 240x480V primary, 120V secondary, 50/60Hz
Schneider Electric 9070TF2000D1 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Complementary
- Depth
- 7.17 in
- Electrical Connection
- screw clamp terminals
- Fuse Type
- 0.41 x 1.50 in CC top
- Height
- 7.46 in
- Material
- copper winding
- Phase
- 1 phase
- Primary Voltage
- 240 x 480 V 120 V || 230 x 460 V 115 V || 220 x 440 V 110 V
- Product Compatibility
- FSC2
- Rated Power In Va
- 2000 VA UL || 2000 VA CSA || 2000 VA NOM || 1500 VA CE
- Temperature Rise
- 115 °C
- Width
- 7.06 in
Contractual warranty
- Warranty
- 18 months
Environment
- Insulation Temperature
- 180 °C
- Nema Degree Of Protection
- not rated (open device)
- Product Certifications
- CSA file LR37055 guide 184-N-90 || UL listed file E61239
Offer Sustainability
- California Proposition 65
- WARNING: This product can expose you to chemicals including: Phenyl glycidyl ether, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- China Rohs Regulation
- Product out of China RoHS scope. Substance declaration for your information.
- Environmental Disclosure
- ENVPEP1308008EN
- Eu Rohs Directive
- Compliant
- Mercury Free
- Yes
- Pvc Free
- Yes
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
- Rohs Exemption Information
- Yes
- Sustainable Offer Status
- Green Premium product
Specifications
- Product Or Component Type
- Industrial Control Transformer
- Range Of Product
- TF
