Description
This time delay unit is an auxiliary that can be combined with an undervoltage release (MN). It must be associated with a 125VDC MN undervoltage release. It eliminates the risk of nuisance tripping due to transient voltage dips lasting from 200ms to 3s. Its power supply is 100-130VDC or 100-130VAC 50/60Hz. This time delay unit has 4 adjustable steps (0.5s - 1s - 1.5s - 3s). It is an external accessory and can be mounted in the switchboard.MN delay unit, MasterPact NT/NW, ComPacT NS, adjustable time delay 0.5s/3s, 100/130VDC, 100/130VAC 50/60Hz, spare part
Schneider Electric 33681 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Complementary
- Accessory / Separate Part Category
- spare part Compact NS630b...1600 || spare part Compact NS1600b...3200
- Impulse Duration
- 200 ms
- Mounting Mode
- external mounting
- Response Time
- 0.5 s || 1 s || 1.5 s || 3 s
- Supply Holding Power
- 4.5 VA
- Supply Inrush Power
- 200 VA
- Threshold Tripping Voltage
- 0.35...0.7 Un open || 0.85 Un close
- Time Delay Range
- 0.5...3 s
Contractual warranty
- Warranty
- 18 months
Offer Sustainability
- California Proposition 65
- WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- China Rohs Regulation
- Product out of China RoHS scope. Substance declaration for your information.
- Eu Rohs Directive
- Compliant
- Mercury Free
- Yes
- Pvc Free
- Yes
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
- Rohs Exemption Information
- Yes
- Weee
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Specifications
- Device Application
- control
- Device Short Name
- MN delay unit
- Product Or Component Type
- time delay relay
- Range Compatibility
- Masterpact (MasterPact NT) || Masterpact (MasterPact NW) || ComPact (ComPact NSX) || ComPact (ComPact NS630b...1600) || ComPact (ComPact NS1600b...3200) || PowerPact (PowerPact Multistandard) || ComPact (ComPact NSXm) || ComPact (ComPact NSX DC) || Masterpact (MasterPact NW UL 489) || Masterpact (MasterPact NT UL 489) || Masterpact (MasterPact NW DC)
- [Uc] Control Circuit Voltage
- 100...130 V AC 50/60 Hz || 100...130 V DC
- Voltage Release Type
- undervoltage release
