Schneider Electric 170AAI14000
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
This product is part of the Modicon Momentum range, an offer of controllers for IP20 monoblock I/Os. This analog input base offers 16 inputs with a full 16bit signed resolution. It offers analog input ranges from 4mA to 20mA, ±10V, ±5V. There is an isolation between channels and ground at 1780V AC, supply and ground at 500V. It is furnished with 2 removable terminal blocks for electrical connection. It features 16 LEDs for channel status signaling. Its dimensions are 141.5mm (width) x 47.5mm (depth) x 125mm (height). It weighs 0.215kg. It is suitable for infrastructures and energy, material handling and simple machine control applications. This product is certified by CE, CSA, FM Class 1 Division 2 and UL. It is suitable for wall mount. Momentum is a flexible, modular family of components that easily snaps together and can be configured for a wide range of distributed I/O and control applications. System with 4 fundamental components that easily snaps together in various combinations to form versatile control systems or subsystems.distributed analog input Modicon Momentum - 16 Input
Schneider Electric 170AAI14000 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Complementary
- Absolute Accuracy Error
- +/- 0.15 % of full scale 25 °C +/- 10 V || +/- 0.15 % of full scale 25 °C +/- 5 V || +/- 0.25 % full scale 25 °C 4...20 mA || +/- 0.25 % full scale 60 °C +/- 10 V || +/- 0.25 % full scale 60 °C +/- 5 V || +/- 0.45 % full scale 60 °C 4...20 mA
- Associated Fuse Rating
- 500 mA, fast blow
- Current Consumption
- 305 mA 24 V DC
- Data Format
- full 16 bits signed
- Depth
- 47.5 mm
- Electrical Connection
- 2 connectors for removable terminal blocks
- External Power Requirement
- +/- 30 V DC
- Full Scale
- 10 V +/- 10 V || 16 mA 4...20 mA || 5 V +/- 5 V
- Height
- 125 mm
- Isolation Between Channels And Ground
- 1780 V AC for 1 minute
- Isolation Between Supply And Ground
- 500 V for 1 minute
- Local Signalling
- for channel status 16 LEDs
- Marking
- CE
- Maximum Power Dissipation In W
- 5.55 W
- Net Weight
- 0.215 kg
- Permissible Common Mode Voltage
- 100 V 47...63 Hz DC between channels to ground || 250 V 47...63 Hz AC between channels to ground
- Protection Type
- internal 2 A slow-blow
- Reverse Polarity Protection
- internal
- Temperature Drift
- 30 %oFS/°C +/- 10 V 60 °C || 30 %oFS/°C +/- 5 V 60 °C || 60 %oFS/°C 4...20 mA 60 °C
- Update Time
- 25 ms
- Width
- 141.5 mm
Contractual warranty
- Warranty
- 18 months
Environment
- Ambient Air Temperature For Operation
- 0-60 °C
- Ambient Air Temperature For Storage
- -40-85 °C
- Operating Altitude
- <= 16404.2 ft (5000 m)
- Product Certifications
- UL || FM Class 1 Division 2 || CSA
- Protective Treatment
- TC
- Relative Humidity
- 95-95 % without condensation
- Resistance To Electromagnetic Fields
- 10 V/m 80...1000 MHz IEC 801-3
- Resistance To Electrostatic Discharge
- 4 kV contact IEC 801-2 || 8 kV on air IEC 801-2
Offer Sustainability
- California Proposition 65
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- China Rohs Regulation
- X
- Circularity Profile
- ENVEOLI1403005EN
- Environmental Disclosure
- ENVPEP1403005EN
- Eu Rohs Directive
- Pro-active compliance (Product out of EU RoHS legal scope)
- Mercury Free
- Yes
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
- Rohs Exemption Information
- Yes
- Sustainable Offer Status
- Green Premium product
- Weee
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Specifications
- Analogue Input Number
- 16
- Analogue Input Range
- 4...20 mA 12 bits < 0.25 Ohm || +/- 10 V 12 bits + sign > 2200 kOhm || +/- 5 V 12 bits + sign > 2200 kOhm
- Analogue Input Type
- single ended
- Product Or Component Type
- analogue input base
- Range Of Product
- Modicon Momentum automation platform
- Type Of Filter
- low pass input filter 10 kHz
