Schneider Electric 140DDO35300
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
discrete output module Modicon Quantum - 32 O solid state
Schneider Electric 140DDO35300 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Complementary
- Absolute Maximum Output
- 56 V 1.3 s decaying pulse
- Addressing Requirement
- 2 output words
- Associated Fuse Rating
- 3 A each point || 5 A per group
- Bus Current Requirement
- 330 mA
- Discrete Output Logic
- positive logic (source)
- Discrete Output Voltage
- 24 V DC
- Fault Indication
- blown fuse || loss of field power
- Group Of Channels
- 4 groups of 8
- Isolation Between Channels And Bus
- 1780 Vrms DC for 1 minute
- Isolation Between Group
- 500 Vrms DC for 1 minute
- Load Inductance
- inductance(H) = 0.5/((current(A))² x (switching frequency(Hz))) 50 Hz
- Local Signalling
- for bus communication is present (Active) 1 LED (green) || for external fault detected (F) 1 LED (red) || for input status 32 LEDs (green)
- Marking
- CE
- Maximum Leakage Current
- 0.4 mA 30 V
- Maximum Load Current
- 16 A per module || 4 A per group
- Maximum Voltage Drop
- <0.4 V 0.5 A
- Module Format
- standard
- Net Weight
- 0.45 kg
- Output Voltage Limits
- 19.2...30 V
- Power Dissipation
- 1.75 W + (0.4 V x total module load current)
- Protection Type
- internal output protection by 5 A fuse per group
- Response Time
- <= 1 ms at state 0 to state 1 || <= 1 ms at state 1 to state 0
- Surge Current
- 5 A 0.0005 s
Contractual warranty
- Warranty
- 18 months
Environment
- Ambient Air Temperature For Operation
- 0-60 °C
- Ambient Air Temperature For Storage
- -40-85 °C
- Operating Altitude
- <= 16404.2 ft (5000 m)
- Product Certifications
- GOST || BV || RMRS || ABS || DNV || GL || RINA || C-tick || FM Class 1 Division 2 || safety certification non interfering
- Relative Humidity
- 95-95 % without condensation
- Resistance To Electromagnetic Fields
- 10 V/m 80-2000 MHz IEC 801-3
- Resistance To Electrostatic Discharge
- 4 kV contact IEC 801-2 || 8 kV on air IEC 801-2
- Standards
- UL 508 || CSA C22.2 No 142
Offer Sustainability
- California Proposition 65
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- China Rohs Regulation
- X
- Circularity Profile
- ENVEOLI0712001EN
- Environmental Disclosure
- ENVPEP071201EN
- Eu Rohs Directive
- Pro-active compliance (Product out of EU RoHS legal scope)
- Mercury Free
- Yes
- Reach Free Of Svhc
- Yes
- Rohs Exemption Information
- Yes
- Sustainable Offer Status
- Green Premium product
- Weee
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Specifications
- Discrete Output Number
- 32
- Product Or Component Type
- dc discrete output module
- Range Of Product
- Modicon Quantum automation platform
