Description
discrete input module Modicon Quantum - 32 I - 24 V DC
Schneider Electric 140DDI35310 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Complementary
- Absolute Maximum Input
- 30 V continuous || 50 V during 1 ms decaying pulse
- Addressing Requirement
- 2 input words
- Bus Current Requirement
- 330 mA
- Current State 0 Guaranteed
- <= 0.5 mA
- Current State 1 Guaranteed
- >= 2.5 mA at Us = - 14 V
- Discrete Input Voltage
- 24 V DC
- Group Of Channels
- 4
- Input Impedance
- 2400 Ohm
- Input Voltage Limits
- 19.2...30 V
- Isolation Between Group
- 500 Vrms for 1 minute
- Isolation Between Group And Bus
- 1780 Vrms for 1 minute
- Local Signalling
- for bus communication is present (Active) 1 LED (green) || for external fault detected (F) 1 LED (red) || for input status 32 LEDs (green)
- Logic Input
- negative (source)
- Marking
- CE
- Maximum Leakage Current
- 200 mA at Us = 5.5 V and Uin = 4 V
- Module Format
- standard
- Net Weight
- 0.3 kg
- Power Dissipation
- 1.5 W + (0.26 x number of points on)
- Protection Type
- input protection by resistor limited
- Response Time
- <= 1 ms from state 0 to state 1 || <= 1 ms from state 1 to state 0
- Voltage State 0 Guaranteed
- -5...0 V DC
- Voltage State 1 Guaranteed
- -30...-15 V DC
Contractual warranty
- Warranty
- 18 months
Environment
- Ambient Air Temperature For Operation
- 0-60 °C
- Ambient Air Temperature For Storage
- -40-85 °C
- Operating Altitude
- <= 16404.2 ft (5000 m)
- Product Certifications
- RINA || GOST || FM Class 1 Division 2 || C-tick || RMRS
- Relative Humidity
- 95-95 % without condensation
- Resistance To Electromagnetic Fields
- 10 V/m 80-2000 MHz IEC 801-3
- Resistance To Electrostatic Discharge
- 4 kV contact IEC 801-2 || 8 kV on air IEC 801-2
- Standards
- UL 508 || CSA C22.2 No 142
Offer Sustainability
- California Proposition 65
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- China Rohs Regulation
- X
- Circularity Profile
- ENVEOLI0712001EN
- Environmental Disclosure
- ENVPEP071201EN
- Eu Rohs Directive
- Pro-active compliance (Product out of EU RoHS legal scope)
- Mercury Free
- Yes
- Reach Free Of Svhc
- Yes
- Rohs Exemption Information
- Yes
- Sustainable Offer Status
- Green Premium product
- Weee
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Specifications
- Discrete Input Number
- 32
- Product Or Component Type
- low voltage dc discrete input modules
- Range Of Product
- Modicon Quantum automation platform
