Schneider Electric 140DAO84000
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
discrete output module Modicon Quantum - 16 O - 20..253 V AC
Schneider Electric 140DAO84000 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Complementary
- Absolute Maximum Output
- 300 Vrms 10 s AC || 400 Vrms 1 cycle AC
- Addressing Requirement
- 1 output word
- Associated Fuse Rating
- 5 A
- Bus Current Requirement
- 350 mA
- Discrete Output Type
- isolated
- Discrete Output Voltage
- 20...253 V AC
- Dv/Dt
- 400 V/ms
- Group Of Channels
- 16 groups of 1 channel
- Local Signalling
- for bus communication is present (Active) 1 LED (green) || for external fault detected (F) 1 LED (red) || for input status 16 LEDs (green)
- Marking
- CE
- Maximum Load Current
- 1 mA rms 24 Vrms off state leakage per output || 1 mA rms 48 Vrms off state leakage per output || 2 mA rms 115 Vrms off state leakage per output || 2.5 mA rms 230 Vrms off state leakage per output || 3 A rms 200...230 V per output || 4 A rms 24...115 V per output || 16 A rms per module || 4 A rms sum of four points, continuous
- Maximum Voltage Drop
- 1.5 V
- Module Format
- standard
- Net Weight
- 0.485 kg
- Power Dissipation
- 1.85 + (1.1 V x total module load current)
- Protection Type
- internal by RC filter
- Response Time
- <= 0.5 ms at state 0 to state 1 || <= 0.5 ms at state 1 to state 0
- Supply Frequency
- 47...63 Hz
- Surge Current
- 10 A during 3 cycles per point || 20 A during 2 cycles per point || 30 A during 1 cycle per point
Contractual warranty
- Warranty
- 18 months
Environment
- Ambient Air Temperature For Operation
- 0-60 °C
- Ambient Air Temperature For Storage
- -40-85 °C
- Electromagnetic Compatibility
- electrostatic discharge immunity test - test level: 4 kV (contact discharge) conforming to IEC 801-2 || electrostatic discharge immunity test - test level: 8 kV (air discharge) conforming to IEC 801-2 || susceptibility to electromagnetic fields - test level: 10 V/m (80...1000 MHz) conforming to IEC 801-3
- Operating Altitude
- <= 16404.2 ft (5000 m)
- Product Certifications
- cUL || FM Class 1 Division 2
- Relative Humidity
- 95-95 % without condensation
- Standards
- UL 508 || CSA C22.2 No 142
Offer Sustainability
- California Proposition 65
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- China Rohs Regulation
- X
- Circularity Profile
- ENVEOLI0712001EN
- Environmental Disclosure
- ENVPEP071201EN
- Eu Rohs Directive
- Pro-active compliance (Product out of EU RoHS legal scope)
- Mercury Free
- Yes
- Reach Free Of Svhc
- Yes
- Rohs Exemption Information
- Yes
- Sustainable Offer Status
- Green Premium product
- Weee
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Specifications
- Discrete Output Number
- 16
- Product Or Component Type
- AC discrete output modules
- Range Of Product
- Modicon Quantum automation platform
