Schmersal 103016678
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
BWU3635
Schmersal 103016678 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Ambient conditions
- Ambient temperature
- -20 ... +60 °C
- Degree of protection
- IP67
- Resistance to vibrations
- 10 … 55 Hz, amplitude 0.5 mm
- Restistance to shock
- 15 g / 11 ms
- Storage and transport temperature, maximum
- +85 °C
- Storage and transport temperature, minimum
- -30 °C
Electrical data - AS Interface
- AS-i Current consumption, maximum
- 60 mA
- Rated operating voltage
- 21.6 ... 31.6 VDC
Electrical data - AS-Interface specification
- AS-i Input, Channel 1
- Data bits DI 0 / DI 1 = dynamic code transmission
- AS-i Input, Channel 2
- Data bits DI 2 / DI 3 = dynamic code transmission
- AS-i Input module address
- 0
- AS-i Outputs, DO 0
- Digital output, Solenoid control
- AS-i Outputs, DO 1 … DO 3
- No Function
- AS-i Parameter bits, P0
- Control system watchdog
- AS-i Parameter bits, P1
- Diagnostics signal safety switchgear (inverted)
- AS-i Parameter bits, P2 ... P3
- No function
- AS-i Profile
- S-7.B.F.1
- AS-i Specification
- Safety-Slave
- AS-i Version
- V 2.1
- Note (AS-i Input module address)
- Preset to address 0, can be changed through AS-interface bus master or hand-held programming device
- Note (AS-i Parameter bits)
- Set the parameter outputs to "1111" (0xF)
Electrical data - Auxiliary voltage
- Operating voltage
- 24 VDC -15 % / +10 % (stabilised PELV power supply)
- Rated operating voltage
- 24 VDC
General data
- Enclosure material
- Plastic
- Gross weight
- 141 g
- Reaction time, maximum
- 11 ms
- Standards
- EN IEC 62026-2 | EN IEC 62061 | EN ISO 13849-1
General data - Features
- Integral system diagnostics, status
- Yes
- Safety functions
- Yes
Mechanical data - Connection technique
- Length of cable
- 1 m
- Material of the cable
- PUR
- Termination
- Cable connector M12, 8-pole, A-coded
Mechanical data - Dimensions
- Depth
- 19 mm
- Height
- 45 mm
- Width
- 60 mm
Safety classification
- Category
- 4
- Mission time
- 20 Year(s)
- Performance Level, up to
- e
- PFD value
- 6.19 x 10⁻⁷
- PFH value
- 5.18 x 10⁻⁹ /h
- Safety Integrity Level (SIL), suitable for applications in
- 3
- Standards
- EN IEC 62061
Specifications
- Depth
- 19 mm
- Height
- 45 mm
- Width
- 60 mm
Status indication
- Note (LED switching conditions display)
- (1) green/red LED (AS-i duo LED): Supply voltage / communication error / slave address = 0 / periphery error detected | (2) LED green: AUX-Power available | (3) LED yellow: S1 = Status safety input 1 | (4) LED yellow: S2 = Status safety input 2 | (5) LED yellow: I1 = Status input I1 | (6) LED yellow: o1 = Status output o1
