Schmersal 103004694
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
ASIM-C-M12-4P-0,5M
Schmersal 103004694 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Ambient conditions
- Ambient temperature
- -20 ... +60 °C
- Degree of protection
- IP67
- Note (Relative humidity)
- non-condensing | non-icing
- Protection class
- III
- Relative humidity, maximum
- 95 %
- Relative humidity, minimum
- 30 %
- Resistance to vibrations
- 10 … 57 Hz, amplitude 0.75 mm
- Restistance to shock
- 30 g / 11 ms
- Storage and transport temperature, maximum
- +80 °C
- Storage and transport temperature, minimum
- -25 °C
Ambient conditions - Insulation values
- Degree of pollution
- 3
- Overvoltage category
- III
- Rated impulse withstand voltage U
- 0.8 kV
- Rated insulation voltage U
- 32 VDC
Approvals - Standards
- Certificates
- TÜV | cULus
Electrical data - AS Interface
- AS-i Current consumption, maximum
- 90 mA
- Rated operating voltage
- 26.5 ... 31.6 VDC (Protection against polarity reversal)
Electrical data - AS-Interface specification
- AS-i Input, Channel 1
- Data bits DI 0 / DI 1 = dynamic code transmission
- AS-i Input, Channel 2
- Data bits DI 2 / DI 3 = dynamic code transmission
- AS-i Input module address
- 0
- AS-i Outputs, DO 0
- No Function
- AS-i Outputs, DO 1 … DO 3
- No Function
- AS-i Parameter bits, P0
- Communication monitoring AS-i
- AS-i Parameter bits, P1 ... P3
- No function
- AS-i Profile
- S-0.B.F.0
- AS-i Version
- V 3.0
- Note (AS-i Input module address)
- Preset to address 0, can be changed through AS-interface bus master or hand-held programming device
- Note (AS-i Parameter bits)
- Set the parameter outputs to "1111" (0xF)
General data
- Duration of risk, maximum
- 5 ms
- Enclosure material
- Thermoplastic PBT
- Gross weight
- 98 g
- Reaction time, maximum
- 1 ms
- Standards
- EN 50295 | EN IEC 62061 | EN ISO 13849-1 | EN IEC 60947-5-1 | EN IEC 60947-5-3 | EN IEC 60947-5-5 | EN IEC 60204-1 | EN IEC 60947-1
General data - Features
- Integral system diagnostics, status
- Yes
- Safety functions
- Yes
Mechanical data - Connection technique
- Length of cable
- 0.5 m
- Material of the cable
- Polyurethane PUR
- Termination
- Connector, M12, 4-pole, A-coded
Mechanical data - Dimensions
- Depth
- 22 mm
- Height
- 40.5 mm
- Width
- 27.7 mm
Safety classification
- Category
- 4
- Mission time
- 20 Year(s)
- Performance Level, up to
- e
- Safety Integrity Level (SIL), suitable for applications in
- 3
- Standards
- EN IEC 62061
Specifications
- Depth
- 22 mm
- Height
- 40.5 mm
- Width
- 27.7 mm
Status indication
- Note (LED switching conditions display)
- (1) green LED (AS-i LED): AS-i supply voltage / Slave address = 0 | (2) red LED: AS-i communication error / Slave address = 0 | (3) yellow LED: I1 = Status safety input 1 | (4) yellow LED: I2 = Status safety input 2 | (5) LED yellow: -
